Standard Hydraulic Hose Crimping Tool 16 Hand Seperated For Field Operation Moving Maintenance
DME&JDE Hose-Crimper 16-Hand Seperated For Field Operation Or Frequent Moving Maintenance
Hose Crimper product introduction
The series of Hose-Crimper 16-Hand Seperated hose crimper machine (Handhebel Type) are the portable types, which are suitable for field operation or frequent moving maintenance. Hose-Crimper 16-Hand Seperated is a highly cost-effective machine developed and designed in collaboration with a French hydraulic team. The small and portable machine is driven by manual hydraulic pump and can be reset mechanically, which greatly reduces the labor intensity. The special material has high strength performance and the glossiness of work surface reaches a highest level after CNC and heat treatment. All of above enable it to be the best choice for your maintenance and field operation!
Hoes Crimper specification
| Max Hydraulic Hose | 25mm ( 2SN ) |
| Crimping Range | 47mm ( 2SN 1” Ferrule ) |
| 【Max EN853 2SN /SAE R2AT 1” (Hose ID : 25mm, Hose OD : 37 mm 】 | |
| Die Type and Quantity | 7 PCS |
| Die Type | 14/16/19/23/27/31/55 mm |
| Max Opening | 52 mm |
| Master Die Length | 55 mm |
| Crimper Speed | Standard |
| Crimping Force | 1000 KN |
| L × W × H | 200 × 260 × 350 mm |
| Weight | 26 KGS |
| Number | Die No. | Crimp Range (mm) | D (mm ) | L (mm) |
|---|---|---|---|---|
| 1 | 14 | 14-16 | 14 | 60 |
| 2 | 16 | 16-19 | 16 | 60 |
| 3 | 19 | 19-22 | 19 | 60 |
| 4 | 23 | 23-27 | 23 | 60 |
| 5 | 27 | 27-31 | 27 | 60 |
| 6 | 31 | 31-35 | 31 | 60 |
| 7 | 35 | 35-39 | 35 | 60 |
Hose Crimper Operating steps
Choose suitable dies as per the crimping data
Adjust the size regulator accordingly
Press the check valve to check whether the indicator is normal
Screw down the unloading valve clockwise
Put the fitting into the machine mouth, keep pressing the hand pump until the light is on.
Unscrew the unloading valve anticlockwise, and take out of the fitting after the mouth is open automatically.
