32 Portable Hose Assembly Equipment 12V Vehicular Hydraulic Crimping Machine
Hose-Crimper 32 Portable 12V Vehicular Hydraulic Crimping Machine
HoseCrimper product introduction
The crimping machine is electro-hydraulic and can be operated by connecting with a 12V storage battery. Crimping machine for hydraulic hose assemblies. The crimping machine comprises a crimping joint A hydraulic unit is mounted on the tank to act as a rack, which can be moved from side to side. This allows it to be installed on trucks, pickup trucks or other moving vehicles. When rolling operation is required, the machine can be easily pushed out of the cab by gently moving to the left and working on the outside of the cab.
Hoes Crimper specification
| Crimp head material | High strength forge steel © "German Industry 4.0" |
| Crimping Diameter Range | 10mm-87mm (*Special sizes can be customized) |
| Capacity of Crimper | 1. Standard Crimper Size:14mm-75mm (*Four steel wires sprial 4SH 2”) 2. Use a Additional purchase of Die Size:10mm-87mm (*Six steel wires sprial R15 2”) |
|
Max Opening |
33 mm 33 mm + 99 mm = 132 mm |
| Pump flow rate | 12 L/min |
| Max Pressure | 275 bar |
| Crimping Force | 2000 kN |
| Motor power | 4000 W |
| Theoretical Production Capacity | 850 times per hour |
| Speed of Master Dies Closing/open | 2.7 mm/s |
| Sound Pressure Level | 71 dB(A) [Reference target: ISO 45001] |
| Oil tank volume | 55 L |
| Oil quantity/ type | 50 L Recommended : Winter: YB-N32 [HM 32] Summer: YB-N46 [HM46] |
| Enclosure Class | IP 54 |
| Weight | 260 kg (Excluding Oil) |
| Size:Length * width * height | 670 * 550 * 1005 mm |
| Foot pedal / switch | Included [Reference target: ISO 45001] |
| Number | Die No. | Crimp Range (mm) | D (mm ) | L (mm) |
|---|---|---|---|---|
| 1 | 10 | 10-12【Additional purchase】 | 10 | 55 |
| 2 | 12 | 12-14【Additional purchase】 | 12 | 55 |
| 3 | 14 | 14-16 | 14 | 55 |
| 4 | 16 | 16-19 | 16 | 55 |
| 5 | 19 | 19-22 | 19 | 55 |
| 6 | 22 | 22-26 | 22 | 70 |
| 7 | 26 | 26-30 | 26 | 70 |
| 8 | 30 | 30-34 | 30 | 70 |
| 9 | 34 | 34-39 | 34 | 75 |
| 10 | 39 | 39-45 | 39 | 75 |
| 11 | 45 | 45-51 | 45 | 90 |
| 12 | 51 | 51-57 | 51 | 90 |
| 13 | 57 | 57-63 | 57 | 100 |
| 14 | 63 | 63-69 | 63 | 110 |
| 15 | 69 | 69-75 | 69 | 110 |
| 16 | 74 | 74-80【Additional purchase】 | 74 | 110 |
| 17 | 78 | 78-87【Additional purchase】 | 78 | 110 |
Special Dies
We provide customized dies machined and with industrial metal additive manufacturing.
We can manufacture special dies :
Supply serve users from over 100 countries
Focus on product quality and warranty time
Specialize in providing solutions and plans
With fast development, test and delivery cycles
Without geometrical manufacturing limits
For the toughest use-cases
