High Precision Hyd Hose Crimper equipment 140 ProMax 4" Max Crimping
Hose-Crimper 140-ProMax 4" Max Crimping High Precision Hydraulic
Hose-Crimper product introduction
The crimping machine is electro-hydraulic and can be operated by connecting 12V battery. The biggest advantage is that you can hold the handles on both sides and it is very convenient to lift the machine and place it in the position that needs to be processed. It can be easily removed and used from trucks, pickup trucks or other moving vehicles.
Hoes-crimper specification
| Compression Range (mm) | 10-124 |
| Maximum Clamping Force | 3200 |
| Number of Deductions (s) | 2000 |
| Hose Size (inches) | 2½ - 4 |
| Mold Stroke (mm) | +82 |
| Min Button Pressing Die D/L (mm) | 190/97 |
| Maximum Opening Diameter(mm ) | 222 |
| Motor Power (KW) | 5.5/7.5 |
| Fuel Tank Capacity (L) | 120 |
|
Machine |
1063 x 737 x 1589 mm |
| 41.9 x 29 x 62.6 inch | |
| Package | 1105 x 945 x 1890 mm |
| 43.5 x 37.2 x 74.4 inch | |
| Station | 713 x 705 x 1059 mm |
| 28.1 x 27.8 x 41.7 inch | |
| Package | 950 x 720 x 1340 mm |
| 37 x 28 x 52.5 inch | |
| Machine | 1063 x 737 x 1589 mm |
|
Machine |
875 N.W. |
| 1120 G.W. | |
| Station | 185 N.W. |
| 275 G.W. |
| Die Set No. | Crimp Range D | L (mm) |
|---|---|---|
| 6 | 6-8 | 55 |
| 8 | 8-10 | 55 |
| 10 | 10-12 | 55 |
| 12 | 12-14 | 55 |
| 14 | 14-16 | 55 |
| 16 | 16-19 | 55 |
| 19 | 19-22 | 70 |
| 22 | 22-26 | 70 |
| 26 | 26-30 | 70 |
| 30 | 30-34 | 70 |
| 34 | 34-39 | 75 |
| 39 | 39-45 | 75 |
| 45 | 45-51 | 90 |
| 51 | 51-57 | 90 |
| 57 | 57-63 | 100 |
| 63 | 63-69 | 100 |
| 69 | 69-75 | 100 |
| 74 | 74-80 | 100 |
| 78 | 78-87 | 100 |
| Die Set No. | Crimp Range D | L (mm) |
|---|---|---|
| P 140/84 | 84-92 | 110 |
| P 140/92 | 92-100 | 110 |
| P 140/100 | 100-108 | 110 |
| P 140/108 | 108-116 | 110 |
| P 140/116 | 116-124 | 110 |
| P 140/124 | 124-132 | 110 |
| P 140/132 | 132-140 | 110 |
Hose-Crimper Process Description
This is a gold grade equipment, because he can curl the maximum size is 4 ", the crimping equipment has high precision, fast speed, continuous production and other characteristics. All are operated by computer and touch screen, with real-time pressure display function, and can also use pressure deduction function. The machine is divided into two parts, and the PUMP has better heat dissipation and can work continuously for a long time
