DP1MMS Straight Hydraulic Hose Connector Heavy 24° Cone Male Straight Hose Fitting
DP1MMS Straight Connector Heavy 24° Cone Male Straight Hose Fitting
Straight Connector product introduction
Straight Connector spcification
| Part Number | F (Thread) | Cone 24° | Ø | C | E | L | S |
|---|---|---|---|---|---|---|---|
| - | Metric | - | Inch | mm | mm | mm | mm |
| DP1MMS-1404 | M14X1.5 | 06S | 1/4" | 12.00 | 6.00 | 51.50 | 14 |
Straight Connector Advantages
Metric 24° Cone Sealing
Adopts the widely recognized metric 24° cone seat, ensuring a robust metal-to-metal seal that resists high pressure, vibration, and temperature fluctuations, meeting European hydraulic system standards.
Heavy-Duty Design
The heavy-type construction enhances load capacity and pressure resistance, making it suitable for extreme high-pressure industrial applications.
Wide Hose Compatibility
Compatible with both braided and spiral hydraulic hoses, offering versatility across heavy machinery, industrial equipment, and mobile hydraulic systems.
Secure Insert Design
The insert structure creates a strong mechanical interlock with the hose core, providing excellent resistance to pull-out and ensuring long-term connection reliability under heavy loads.
Straight Flow Path
The straight-through design minimizes flow resistance, supporting efficient fluid transmission and reducing pressure loss in high-pressure hydraulic circuits.
Standardized Quality
Manufactured to strict international hydraulic standards, guaranteeing consistent performance and full compatibility with standard hydraulic crimping equipment.
