LAKER AUTO Classic D102 2 Seats Electric Golf Cart Car with 48V/5KW AC Motor and 70km Range
About D102
Data Sheet
| 2 Seats Electric Lifted Golf Cart D1H4+2 | |
| Size (L*W*H) | 2420*1350*2010mm |
| Qty/20'GP(Disassembled) | 4 Units |
| Qty/40'GP(Disassembled) | 12 Units |
| Specifications | |
| Passenger Capacity | 2 Seats |
| Max. Speed | 40km/h(Adjustable) |
| Range (loaded) | 70km |
| Climbing Ablity(loaded) | 20% |
| Braking Distance | ≤4.5m |
| Min.Turning Radius | ≤5m |
| Min.Clearance | 180mm |
| Power System | |
| Motor | 48V/5KW AC motor |
| Controller | 48V 350A Controller |
| Battery | 6pcs*8V 150Ah Lead-acid Battery |
| Charger | 110V AC to DC 48V 20A Smart On-board Charger |
| Charger Time | 8-10 hours |
| Dimensions | |
| F/R Tread | Front 1020mm/Rear 2060mm |
| Axle Distance | 2420mm |
| Curb Weight | ≤770kg(with battery) |
| Max.loading | 510kg |
About D1 Series
The vehicle's body features a dynamic three-dimensional design. Its front end presents a structured, multi-layered appearance, complemented by a sleek windshield and integrated sunshade. The side profile is characterized by clean, flowing lines. Inside, the black seats are ergonomically shaped to deliver superior comfort and support, contributing to a modern and commanding overall aesthetic.
The car is fitted with a CMOS continuously variable transmission system, incorporating intelligent features like automatic electronic braking and anti-rollback protection. It also includes automatic downhill speed control to ensure safe and smart operation. Up front, a double-wishbone independent suspension works in tandem with coil springs and telescopic hydraulic shock absorbers to effectively absorb road imperfections and enhance ride smoothness.
About LAKER AUTO
Having deeply rooted in overseas markets for years, LAKER AUTO accurately grasps global customer needs, fully understands the strengths and weaknesses of Chinese EV vehicle manufacturers and products, precisely identifies the standards of EV models suitable for overseas markets, and integrates high-quality manufacturer resources, focusing on the customized R&D and global export of a full range of mobile products, covering various scenario-specific models, including:
· Recreational & Sightseeing: Golf carts (2-8 seater) for courses/estates; Sightseeing buses (8-23 seater) for resorts/parks.
· Industrial & Utility: Industrial golf carts, utility vehicles (UTVs), and tracked carriers.
· Emergency & Sanitation: Water sprinklers, fire trucks, sanitation trucks, and emergency toilet vehicles.
· Support Trailers: Enclosed cargo trailers, mobile food carts, and mobile toilet trailers.
More than a provider of high-quality mobile tools, we take scenarios as the core, creating customized solutions for global customers to meet multi-dimensional needs such as leisure, business and emergency, empowering the upgrade of scenario value.
