132KW Direct-driven Water Cooling Oil-free Rotary Screw Compressor
Price:
Negotiable
MOQ:
1 unit
Delivery Time:
5-15 days
Brand:
AIRERA
Product Description
AIRERA 132kW Direct-Driven Oil-Free Water-Cooled Compressor: Massive Power with Zero-Compromise Purity
As the heavy-duty flagship of the AIRERA family, the 132kW series is engineered for ultra-large factories seeking peak productivity. Featuring high-efficiency direct-drive technology, it converts full motor power into compressed air, significantly boosting energy utilization during high-flow operations. With its core 100% oil-free compression, it consistently delivers ultra-clean air meeting ISO Class 0 standards, providing a solid safeguard for medical manufacturing, precision electronics, and high-end industries. Paired with its superior heavy-duty water-cooling system, the unit remains cool under extreme loads, achieving a perfect harmony of durability and high performance.
Advantages of OGFD Air Screw Compressor:
- Water cooler
- Relief valve
The independently designed unloading valve (Patent No.: ZL200520058468.2), specifically engineered for vortex characteristics, enables fully sealed operation in screw compressors, ensuring stepless air delivery from 0 to 100%.
- Imported softeners
Used to remove scale from cooling water and effectively prevent the precipitation of impurities, ensuring unobstructed compressor piping. It has a maximum service life of 3 years.
Technical Specifications - 132KW Air Cooling Compressor
132KW Air Cooling Compressor Parameters
| ITEM | UNIT | MODEL OGFD-132 |
|---|---|---|
| Free air delivery | m³/min | 25.0-20.0 |
| Max. working pressure | MPa | 0.7-1.0 |
| Compressor type | Oil-free screw compressor | |
| Cooling type | Wate cooling | |
| Driven type | Direct driven | |
| Inlet status - Temperature | ℃ | ≤45 |
| Inlet status - Pressure | MPa | Atmospheric pressure |
| Inlet status - Relative humidity | ≤90% | |
| Noise Level | dB(A) | ≤77 |
| Drive rotor speed | rpm | 2990 |
| Compressed air outlet temperature | ℃ | Ambient temperature＋15 |
| Compressed Inlet temp. | ℃ | 2-40 |
| Cooling water flow | m3/min | 320 |
| Control mode | Intelligent controller | |
| Safety valve set pressure | MPa | 0.77 ~ 1.10 |
| Lubricating water volume | L | 240 |
| Compressed air outlet connection | DN80 | |
| Dimension - L | mm | 2350 |
| Dimension - W | mm | 1600 |
| Dimension - H | mm | 1680 |
| Net Weight | kg | 3500 |
| Motor - Model | Y2280M2-2 | |
| Motor - Speed | rpm | 2990 |
| Motor - Rated Power | KW | 132 |
| Motor - Service factor | 1.2 | |
| Motor - Protection type | IP55 | |
| Motor - Efficiency | IE3 | |
| Motor - Startup mode | ʏ-Δ starting | |
| Motor - Voltage | V | 380 |
| Motor - Frequency | Hz | 50 |
| Motor - Rated current | A | 242 |
| Motor - Weight of motor | kg | 1010 |
AIRERA 132kW Screw Air Compressor: Frequently Asked Questions (FAQ)
How does the 132kW model ensure air pressure stability for large-scale production lines?
The 132kW model features an immense displacement (approx. $23.0 - 25.0text{ m}^3text{/min}$), easily handling instantaneous peak demands from multiple parallel devices. Coupled with an intelligent control system, it precisely regulates discharge pressure to prevent product defects caused by pressure fluctuations.
How does the "Water-Cooling System" perform under extreme heavy-load conditions?
The AIRERA 132kW utilizes thickened copper-tube heat exchangers with multi-layer anti-corrosion treatments. Even under 100% full-load operation 24/7, its efficient heat exchange surface area rapidly dissipates heat, ensuring air-end bearings and seals work under low temperature rises to extend the overall service life.
Why is "Oil-Free" more emphasized for high-power equipment like the 132kW model?
In ultra-large-scale production (such as medical or semiconductors), a tiny amount of oil contamination can lead to the scrapping of entire product batches. As the core power source, the Class 0 oil-free guarantee of the 132kW unit is the final line of defense against massive economic losses.
