AGCD-280D II B VP Screw Air Compressor, Specifically Designed for Factory Energy-Saving Retrofits; Two-Stage Compression Saves 30%+ on Electricity Costs
The AIRERA AGCD-280D II B VP screw air compressor is specifically engineered for mega-scale, low-carbon factory energy retrofits in heavy industries. Seamlessly integrating high-displacement two-stage compression technology with a high-capacity smart VSD system, this model guarantees a continuous, massive supply of compressed air while delivering an impressive 30%+ reduction in electricity consumption compared to conventional single-stage machinery. Its high-strength, integrated chassis ensures maximum durability and continuous uptime in punishing environments, serving as the absolute technical backbone for energy-intensive enterprises to replace inefficient legacy systems and achieve lean manufacturing with minimized operational costs.
-
Expanded filtering system design
Multiple air filter designs, more durable and stop much more particles outside, protect inlet system of compressor for long time working outdoor & indoor environment.
-
Efficient after cooler
The cooler adopts a new type of threaded finned tube shell-and-tube heat exchanger, and the compressed air goes inside the tube. The advantages are as follows: a. The compressed air goes through the tube, which improves the pressure bearing capacity compared with the outer finned tube.
- Independent air intake system
Independent air intake ensures that the intake air temperature is equal to the ambient temperature. Large-capacity air filter is used to achieve better filtering effect, lower intake pressure loss, and energy saving and high efficiency. Maintenance and replacement are more convenient.
| ITEM | UNIT | MODEL AGCD-280II VP |
|---|---|---|
| Air capacity | m³/min | 22.58-56.45|20.60-51.5|20.36-50.90|17.40-43.50 |
| Working pressure | MPa | 0.7~1.3 |
| Compressor type | Oil inject dual stage screw compressor | |
| Cooling type |
Air cooling |
|
| Driven type | Direct driven | |
| Inlet status Temperature | ℃ | ≤45 |
| Inlet status Pressure | MPa | Atmospheric pressure |
| Inlet status Relative humidity | ≤90% | |
| Noise Level | dB(A) | ≤79 |
| Residual oil content | ppm | ≤2 |
| Drive rotor speed | rpm | 1500 |
| Compressed air outlet temperature | ℃ | Ambient temperature＋10 |
| Cooling air flow | m3/hr | 19200 |
| Control mode | Intelligent controller | |
| Safety valve set pressure | MPa | 0.77-1.43 |
| Lubricating oil volume | L | 110 |
| Lubricating oil brand | ROTORCOMP | |
| Compressed air outlet connection | DN100 | |
| Dimension L | mm | 3450 |
| Dimension W | mm | 2000 |
| Dimension H | mm | 2200 |
| Net Weight | kg | 5700 |
| Motor Model | YPM-355L1-8 | |
| Motor Speed | rpm | 1500 |
| Motor Rated Power | KW | 250 |
| Motor Service factor | 1.2 | |
| Motor Protection type | IP55 | |
| Motor Efficiency | IE3 | |
| Motor Startup mode | Frequency conversion starting | |
| Motor Voltage | V | 380(Special on request) |
| Motor Frequency | Hz | 80-200 |
| Motor Rated current | A | 500 |
| Motor Weight of motor | kg | 1610 |
The R&D team configured this titanic compressor with high-damping heavy-duty thickened anti-vibration bases and a next-generation fully-enclosed silent acoustic enclosure, isolating operational vibrations and mechanical noise within the chassis. Even in dense, high-power, continuous full-load output retrofit sites, it maintains an exceptional state of smooth running, completely avoiding potential interference to neighboring precision instruments caused by severe vibration in legacy machinery to fully optimize the infrastructure environment of smart green plants.
Beyond cutting massive electricity expenses with its 30%+ energy efficiency, this model leverages the technological advantages of a low-speed two-stage airend to significantly lower the overall mechanical friction load on internal drive and lubrication systems. This premium architecture greatly extends the replacement cycles of core consumables such as specialized compressor oil and precision filters, minimizing component wear and routine maintenance frequency in long-term operations to help energy-intensive groups maximize the release of asset value through exceptional industrial durability.
