AGCD-400D II B VP Quiet Air Compressor for Medical Cleanrooms—Two-Stage Permanent Magnet Screw Compressor for Clean Air Supply
The AIRERA AGCD-400D II B VP is a premium air compressor specifically engineered for Medical and cleanroom environments. Integrating advanced two-stage compression technology with a permanent magnet variable speed drive (VSD), this model ensures exceptional air purity while delivering ultimate energy efficiency and high-performance operation. Tailored to meet the stringent environmental standards of the Medical industry, it features a comprehensive low-noise design for whisper-quiet operation, seamlessly blending into high-standard cleanrooms. As a reliable power core, AIRERA delivers a stable, pure, and contamination-free compressed air supply for manufacturing, packaging, and laboratory applications, making it the ideal choice for modern Medical process upgrades.
-
Efficient after cooler
The cooler adopts a new type of threaded finned tube shell-and-tube heat exchanger, and the compressed air goes inside the tube. The advantages are as follows: a. The compressed air goes through the tube, which improves the pressure bearing capacity compared with the outer finned tube.
-
Noise reduction sheet metal design
Multiple noise reduction designs, calculated according to noise science, with special flame-retardant and sound-absorbing cotton inside to reduce unit noise.
- Independent air intake system
Independent air intake ensures that the intake air temperature is equal to the ambient temperature. Large-capacity air filter is used to achieve better filtering effect, lower intake pressure loss, and energy saving and high efficiency. Maintenance and replacement are more convenient.
| ITEM | UNIT | MODEL AGCD-400II VP |
|---|---|---|
| Air capacity | m³/min | 34.16-85.4|32.76-81.90|28.96-72.40|25.92-64.80 |
| Working pressure | MPa | 0.7~1.3 |
| Compressor type | Oil inject dual stage screw compressor | |
| Cooling type |
Air cooling |
|
| Driven type | Direct driven | |
| Inlet status Temperature | ℃ | ≤45 |
| Inlet status Pressure | MPa | Atmospheric pressure |
| Inlet status Relative humidity | ≤90% | |
| Noise Level | dB(A) | ≤79 |
| Residual oil content | ppm | ≤2 |
| Drive rotor speed | rpm | 1500 |
| Compressed air outlet temperature | ℃ | Ambient temperature＋10 |
| Cooling air flow | m3/hr | 26200 |
| Control mode | Intelligent controller | |
| Safety valve set pressure | MPa | 0.77-1.43 |
| Lubricating oil volume | L | 200 |
| Lubricating oil brand | ROTORCOMP | |
| Compressed air outlet connection | DN150 | |
| Dimension L | mm | 4500 |
| Dimension W | mm | 2500 |
| Dimension H | mm | 2200 |
| Net Weight | kg | 11500 |
| Motor Model | YEVP-450L1-4 | |
| Motor Speed | rpm | 1500 |
| Motor Rated Power | KW | 400 |
| Motor Service factor | 1.2 | |
| Motor Protection type | IP55 | |
| Motor Efficiency | IE3 | |
| Motor Startup mode | Frequency conversion starting | |
| Motor Voltage | V | 380(Special on request) |
| Motor Frequency | Hz | 25-50 |
| Motor Rated current | A | 710 |
| Motor Weight of motor | kg | 2450 |
Specially engineered for Medical environments, this model delivers an air supply that complies with stringent purity standards. Utilizing high-precision filtration systems and an optimized internal structure, it effectively prevents oil and particulate contamination in the compressed air. It provides completely pure, sterile, and contamination-free air for manufacturing, filling, and laboratory applications, meeting strict GMP cleanroom standards.
The machine features comprehensive soundproofing and noise-reduction engineering. The interior enclosure is lined with high-density acoustic insulation, paired with a low-speed screw air-end and a quiet cooling fan to eliminate mechanical resonance and aerodynamic noise. Even under full load, it maintains an exceptionally low noise level, making it ideal for equipment rooms adjacent to cleanrooms or laboratories without disrupting high-standard working and manufacturing environments.
