AGCD-500D II B VP Quiet Air Compressor for Pharmaceutical Cleanrooms—Two-Stage Permanent Magnet Screw Compressor for Clean Air Supply
The AIRERA AGCD-500D II B VP is a premium air compressor specifically engineered for high-standard pharmaceutical cleanrooms. Integrating advanced two-stage screw compression technology with a highly efficient permanent magnet variable speed drive (VSD), it not only delivers an ultra-pure, contamination-free clean air supply but also achieves exceptional energy efficiency. Tailored to meet the strict noise regulations of pharmaceutical manufacturing and laboratory environments, this model features a comprehensive soundproofing design for whisper-quiet operation. As a core power source, it supplies continuous, stable, and hygienic compressed air for high-precision medicine production, precise packaging, and pharmaceutical R&D, making it the ideal choice for modern pharmaceutical process upgrades.
-
Industry-leading air host
The air compression chamber is completely separated from the oil chamber. The air side adopts a non-abrasive sealing system with a spring-loaded metal ring, and the lubricating oil side adopts a non-abrasive sealing system with a copper labyrinth seal. The two do not contact.
-
Reliable hydraulic intake valve
The high-efficiency intake valve adopts hydraulic control, which makes the work more stable and reliable, avoids the regular replacement of pneumatic components, and reduces unnecessary downtime and maintenance costs.
- Independent air intake system
Independent air intake ensures that the intake air temperature is equal to the ambient temperature. Large-capacity air filter is used to achieve better filtering effect, lower intake pressure loss, and energy saving and high efficiency. Maintenance and replacement are more convenient.
| ITEM | UNIT | MODEL AGCD-500II VP |
|---|---|---|
| Air capacity | m³/min | 46.36-115.9|43.5-108.9|40.58-101.45|33.92-84.80 |
| Working pressure | MPa | 0.7~1.3 |
| Compressor type | Oil inject dual stage screw compressor | |
| Cooling type |
Air cooling |
|
| Driven type | Direct driven | |
| Inlet status Temperature | ℃ | ≤45 |
| Inlet status Pressure | MPa | Atmospheric pressure |
| Inlet status Relative humidity | ≤90% | |
| Noise Level | dB(A) | ≤79 |
| Residual oil content | ppm | ≤2 |
| Drive rotor speed | rpm | 1500 |
| Compressed air outlet temperature | ℃ | Ambient temperature＋10 |
| Cooling air flow | m3/hr | 31200 |
| Control mode | Intelligent controller | |
| Safety valve set pressure | MPa | 0.77-1.43 |
| Lubricating oil volume | L | 200 |
| Lubricating oil brand | ROTORCOMP | |
| Compressed air outlet connection | DN200 | |
| Dimension L | mm | 4500 |
| Dimension W | mm | 2500 |
| Dimension H | mm | 2200 |
| Net Weight | kg | 12900 |
| Motor Model | YEVP-500L2-4 | |
| Motor Speed | rpm | 1500 |
| Motor Rated Power | KW | 500 |
| Motor Service factor | 1.2 | |
| Motor Protection type | IP55 | |
| Motor Efficiency | IE3 | |
| Motor Startup mode | Frequency conversion starting | |
| Motor Voltage | V | 380(Special on request) |
| Motor Frequency | Hz | 25-50 |
| Motor Rated current | A | 895 |
| Motor Weight of motor | kg | 2650 |
How does the control system of this air compressor assist pharmaceutical plants in meeting modern workshop management and compliance requirements?
The machine is equipped with an intelligent microcomputer control system that supports remote monitoring and various industrial communication protocols (such as Modbus). It records critical real-time data, including discharge pressure, temperature, running hours, and maintenance cycles. This highly digitalized management style seamlessly integrates with the smart central control rooms of pharmaceutical enterprises (complying with GMP or relevant data integrity specifications), enabling secure traceability and unattended operation of the air supply system.
How does this two-stage compressor maintain stable performance in hot or highly humid climates?
This is another major advantage of two-stage compression. A highly efficient intercooler is engineered between the two stages of the screw air-end. The hot gas generated from the first stage is rapidly cooled before entering the second stage for final compression. This significantly lowers the overall operating temperature of the machine, effectively retards oil degradation, and enhances the system's moisture removal efficiency, ensuring the equipment consistently delivers dry, high-quality, contamination-free air even under harsh ambient conditions.
This model utilizes a fully enclosed, high-protection-grade permanent magnet synchronous motor, which eliminates the bearing wear risks found in conventional motors and achieves a drive efficiency above 99%. The PM VSD system features a "soft start" function where the starting current rises smoothly from zero, completely eliminating electrical grid spikes and mechanical shocks to the gears. With lower operating temperatures and significantly reduced mechanical stress, the machine boasts an extremely low failure rate and a prolonged lifespan for core components, substantially lowering the enterprise's long-term equipment maintenance expenditures.
