600x1200mm Aluminum Formwork Panels High Strength Aluminum Shuttering Panels
Price:
US $97.00 - 130.00/ Square Meter
MOQ:
50 piece
Delivery Time:
10-30 workday
Brand:
WKS
Product Description
600x1200mm Aluminum Frame Formwork Deck Panel for Concrete Slab Construction
Aluminum Frame Formwork is a lightweight, high-strength modular system engineered for fast-cycle construction of high-rise residential and commercial buildings. It combines extruded aluminum alloy frames with durable plywood or composite panels to deliver exceptional efficiency and precision for wall and slab forming.
Features & Functions
- Lightweight & Fast Assembly: Significantly lighter than steel systems (~25-30 kg/m²), it enables manual handling and rapid installation without heavy cranes, drastically reducing labor time and equipment costs.
- High Precision & Smooth Finish: The rigid aluminum frame ensures minimal deflection, producing high-quality, plaster-free concrete surfaces with tight dimensional tolerances for doors and windows.
- Fast-Cycle Construction: Designed for quick strip and re-erection, supporting efficient floor-to-floor cycle times (typically 4-5 days per floor) with integrated early-strike capabilities.
- Corrosion Resistant: Naturally resistant to rust and weathering, ensuring long-term durability and a clean appearance even after multiple reuses.
Key Specifications
- Frame Material: 6061-T6 / 6082-T6 Aluminum Alloy
- Panel: 15mm / 18mm Film Faced Plywood or Plastic Composite
- Standard Sizes: 400x2400mm, 600x2400mm, 900x2400mm (Modular)
- Allowable Concrete Pressure: 60 - 80 kN/m²
- Typical Weight: 25 - 35 kg/m²
Technical Specifications
| No | Item | Data |
|---|---|---|
| 1 | Weight | ≈24kg/sqm |
| 2 | Plywood Panel Thickness | 12mm/15mm/18mm |
| 3 | Plywood Panel Material | Birch, poplar, eucalyptus, mixed or Plastic plywood |
| 4 | Aluminum Frame Material | 6061-T6 |
| 5 | Aluminum Frame Height | 100mm/120mm |
| 6 | Max Size of Wall & Column | 1000mm*3000mm |
| 7 | Max Size of Slab | 1800mm*2400mm |
| 8 | Maximum Concrete Pressure | 60kN/sqm |
| 9 | Coating of aluminum frame | Powder coating |
Competitive Advantages
- Optimal Lifecycle ROI: Offers the best balance of initial cost, high reusability (frames last for hundreds of cycles), and low operational expense, outperforming both steel and wood in repetitive projects.
- Labor & Time Savings: The lightweight design and pin-and-wedge connection system significantly reduce erection and stripping time compared to traditional formwork.
- Zero Waste & High Scrap Value: Aluminum frames are 100% recyclable at end-of-life, providing substantial residual value and supporting sustainable construction practices.
- Advanced production equipment and 20 years of production experience
- Team of engineers with an average of about 10 years of experience ensures smooth project progress
- Full cycle project services to ensure smooth application of aluminum frame formwork
One Stop Solution Service Process
- Free Consultation Service: You provide us with construction drawings to evaluate which formwork system solution is more cost-effective and provide a detailed quotation list for you.
- Full Process One-on-One Project Team Service: Each project will have an independent team to provide you with professional engineering solution services, business communication services, and on-site construction management services.
- Project Emergency Plan Service: The project scheme formulation process will cautiously consider the emergency handling of aluminum alloy formwork system products during use.
Frequently Asked Questions
Do you provide samples? Is the sample chargeable or free?
Yes, we can provide small size samples. If you need big size samples, you need to pay for them. You will also need to pay for the shipping cost.
Yes, we can provide small size samples. If you need big size samples, you need to pay for them. You will also need to pay for the shipping cost.
Are you a trading company or a manufacturer?
We are a subsidiary foreign trade company of a group company, mainly responsible for operating the export business of formwork and scaffolding products. Our group company has two major production bases, specializing in the production and processing of formwork and scaffolding products for over 20 years.
We are a subsidiary foreign trade company of a group company, mainly responsible for operating the export business of formwork and scaffolding products. Our group company has two major production bases, specializing in the production and processing of formwork and scaffolding products for over 20 years.
How to get quotation?
For simple concrete pouring projects with your own engineer, provide us with a bill of materials for quotation. For complex projects like apartments and residences, our professional consultants will develop an application plan based on your engineering architectural drawings and provide a quotation.
For simple concrete pouring projects with your own engineer, provide us with a bill of materials for quotation. For complex projects like apartments and residences, our professional consultants will develop an application plan based on your engineering architectural drawings and provide a quotation.
What can we supply for you?
A comprehensive range of scaffolding, formwork accessories and safety products for the construction industries. We also design and produce steel items as per client requests, providing all kinds of scaffolding for your needs.
A comprehensive range of scaffolding, formwork accessories and safety products for the construction industries. We also design and produce steel items as per client requests, providing all kinds of scaffolding for your needs.
How can you guarantee that we will get better service and high quality products?
Advanced automated production lines, experienced workers, quality inspection teams, and chemical/physical laboratories ensure high quality products. Our engineering team provides technical support and our sales team offers one-on-one business communication through various platforms.
Advanced automated production lines, experienced workers, quality inspection teams, and chemical/physical laboratories ensure high quality products. Our engineering team provides technical support and our sales team offers one-on-one business communication through various platforms.
How long is the estimated delivery time after the contract is signed?
According to project complexity, it usually takes 30-60 days to complete stocking. We provide more accurate delivery time estimates during the planning and quotation process.
According to project complexity, it usually takes 30-60 days to complete stocking. We provide more accurate delivery time estimates during the planning and quotation process.
What is your terms of payment?
T/T 30% deposit payment before manufacture, and 70% balanced payment against B/L Copy. Or L/C.
T/T 30% deposit payment before manufacture, and 70% balanced payment against B/L Copy. Or L/C.
