Red High Adhesion Easy Tear Silicone Masking Tape For Professional Painting 200um±20um
This red masking tape is a high-grade composite tape, constructed with a red masking paper backing and a high-performance silicone adhesive system, reinforced by a PET polyester film layer. It delivers exceptional mechanical strength, abrasion resistance, and tear resistance, ensuring reliable performance in demanding industrial processes.
After high-temperature lamination, the tape can be cleanly removed without leaving any residue, making it ideal for precision applications. It is specifically designed for masking and protection during printed circuit board (PCB) soldering and wave soldering operations, effectively preventing electroplating solutions from penetrating sensitive areas.
- PCB Soldering Masking,used for masking and protection during printed circuit board (PCB) soldering processes.
- Wave Soldering Protection,applied to shield critical areas during wave soldering operations.
- Electroplating Solution Barrier,prevents electroplating solutions from penetrating and contaminating sensitive components.
- High-Temperature Lamination Masking,provides reliable masking during high-temperature lamination processes.
- Component Protection in Electronics Assembly,protects electronic components from heat, chemicals, and physical damage during assembly.
- SMT Process Masking,used for masking in surface mount technology (SMT) reflow and assembly lines.
| Item | Specification | Standard / Remark |
|---|---|---|
| Total Thickness | 200 ± 20 μm | GB/T 7125-2014 |
| Adhesion Strength | > 1000 g / 25 mm (180°) | GB/T 2792-1998 |
| Temperature Resistance | 180°C for 30 minutes | Oven test |
- Temperature: 23 ± 1 °C
- Humidity: 50 ± 5%
- Adherend: Steel plate
- Peel speed: 300 mm/min
- Peel angle: 180°
Sanfeng Win New Materials (Jiangsu) Co., Ltd. (hereinafter referred to as Sanyifeng) was established in 2010. It is a private enterprise integrating R&D, production and sales of adhesive products, with industry-leading coating technology and a professional R&D team. The company specializes in the production of high-temperature resistant tapes, optical protective films, new energy battery blue films, aerogel packaging hot-pressing films, photovoltaic perforated tapes, photovoltaic backsheets and other products, which are widely used in electronics, mobile phone screens, PCB, powder spraying, insulation, die-cutting, printing plastics, battery cell aluminum case wrapping, FPC, new energy, photovoltaic and other industries.
To ensure product quality requirements, the company is equipped with precision coating equipment and professional R&D and technical talents.
The company has a high-purification clean workshop and a multi-functional composite precision coating production line, providing customers with R&D, design schemes and market application feedback, and can put into independent mass production services.
It is a high-grade tape designed for masking and protection in PCB soldering, wave soldering, and electroplating processes, where it prevents solution penetration and residue after high-temperature exposure.
It can withstand a temperature of 180°C for 30 minutes, verified through oven testing.
The total thickness is 200 ± 20 μm, tested per the standard GB/T 7125-2014.
No, it is formulated with a high-performance silicone adhesive that can be cleanly removed without leaving residue after high-temperature lamination.
All specifications are tested under standard conditions: temperature 23 ± 1°C, humidity 50 ± 5%, on a steel plate, with a peel speed of 300 mm/min and a peel angle of 180°.
The adhesion strength is greater than 1000 g / 25 mm (180°), tested according to the standard GB/T 2792-1998.
