60µm Thickness PET Tape with 180°C Heat Resistance and Residue-Free Removal
TX5010W is a 60μm white PET tape with brown silicone adhesive. It offers excellent initial adhesion, no residue after peeling, and high temp resistance up to 180°C. Ideal for masking, bonding, and LCD panel protection.
- LCD Panel & Screen Protection
- PDA Glass Bonding & Fixing
- Housing Painting High-Temp Masking
- Silicone Rubber Material Bonding
- Electronics Component Assembly
- High-Temp Process Masking & Fixing
| Item | Specification | Standard |
|---|---|---|
| Active Layer Thickness | 60±5μm | GB/T7125-2014 |
| Adhesive Thickness | 10±5μm | GB/T7125-2014 |
| Adhesion Strength | 600g/25.4mm (180° peel) | GB-T2792-2014 |
| Temperature Resistance | 180°C/30mins (Oven Test) | - |
| Substrate | White PET Film | - |
| Adhesive Type | Brown Silicone Adhesive | - |
| Test Conditions | 23±1°C, 50±5% RH, Steel Plate, 300mm/min, 180° Peel | - |
Sanfeng Win New Materials (Jiangsu) Co., Ltd. (Sanfeng Win), founded in 2010, is a private enterprise integrating R&D, production, and sales of adhesive products. With industry-leading coating technology and a professional R&D team, we specialize in high-temperature resistant tapes, optical protective films, new energy battery blue films, aerogel packaging hot-pressing films, photovoltaic perforated tapes, and backsheets. Our products are widely used in electronics, mobile phone screens, PCB, powder spraying, insulation, die-cutting, printing plastics, battery cell aluminum case wrapping, FPC, new energy, and photovoltaic industries. Equipped with precision coating equipment, a high-purification clean workshop, and a multi-functional composite precision coating production line, we provide customers with R&D, design solutions, and market application feedback, enabling independent mass production services to ensure product quality.
- What is the substrate material of this tape? It uses a 60μm white PET (polyester) film base for excellent dimensional stability.
- What type of adhesive is used? It features a brown silicone adhesive with good self-absorption and no residue after peeling.
- What is the maximum temperature resistance? It can withstand high temperatures up to 180°C for 30 minutes (Oven Test).
- Can it be peeled without leaving residue? Yes, it offers excellent self-absorption and can be repeatedly peeled without residue.
- What is the adhesion strength performance? The adhesion strength reaches 600g/25.4mm (180° peel), ensuring reliable bonding.
- What is the recommended storage condition? Store in a cool, dry place away from direct sunlight (18-25°C, 40-70% RH) with a 6-month shelf life.
