Anti Static Japanese Washi Masking Tape with 100 μm thickness for Furniture Industry
The MST8813 Series is a high-performance crepe paper masking tape coated with a rubber-based adhesive. With a total thickness of 100μm, it offers stable performance and moderate adhesion, making it ideal for general industrial applications and electronics manufacturing. The tape provides excellent masking and protective properties, suitable for positioning, bundling, and temporary surface protection.
-
Masking and protection in electronics assembly
-
General industrial positioning and packaging
-
Temporary surface protection during painting or coating
-
Bundling and fixing in manufacturing processes
-
Suitable for applications requiring heat resistance up to 100°C for 30 minutes
Structure
| NO | Material | Remarks | |
| 1 | Structure | Crepe Paper | Crepe Paper |
| 2 | Adhesive Type | Rubber | |
| Parameter | Value | Test Standard |
|---|---|---|
| Total Thickness | 100 ± 10 μm | GB/T4513-2002 |
| Peel Strength | 500g±200g/25.4mm(180°) | GB/T2792-2014 |
| Tensile Strength | ≥40N/ 25.4 mm | GB/T12914-2008 |
| Elongation | ≥15% | GB/T12914-2008 |
| Surface Resistance | 106-9 | GM3110 |
| Temperature Resistance | 100°C / 30 min | SUS Plate Test |
-
Temperature: 23 ± 1°C
-
Relative Humidity: 50 ± 5% RH
-
Peel Angle: 180°
-
Pull Speed: 300 mm/min
-
Test Plate Material: Steel (SUS)
Sanfeng Win New Materials (Jiangsu) Co., Ltd. (hereinafter referred to as Sanfeng Win) was established in 2010. It is a private enterprise integrating R&D, production and sales of adhesive products, with industry-leading coating technology and a professional R&D team. The company specializes in the production of high-temperature resistant tapes, optical protective films, new energy battery blue films, aerogel packaging hot-pressing films, photovoltaic perforated tapes, photovoltaic backsheets and other products, which are widely used in electronics, mobile phone screens, PCB, powder spraying, insulation, die-cutting, printing plastics, battery cell aluminum case wrapping, FPC, new energy, photovoltaic and other industries.
To ensure product quality requirements, the company is equipped with precision coating equipment and professional R&D and technical talents.
The company has a high-purification clean workshop and a multi-functional composite precision coating production line, providing customers with R&D, design schemes and market application feedback, and can put into independent mass production services.
Max width: 1300mm
Standard widths: 500mm, 1040mm, 1090mm, 1280mm
