904L Hexagonal Stainless Steel Bar with JIS Standard TSHS Surface Finish and High Corrosion Resistance
904L Hexagonal Stainless Steel Rod Bar JIS Standard TSHS Surface Finish High Quality Customized Industrial Construction Steel
We are a professional manufacturer specializing in high-quality 904L hexagonal stainless steel rod/bar, strictly produced in accordance with JIS standard, featuring TSHS surface finish, and providing comprehensive customized services to fully meet the strict requirements of industrial construction and various high-demand industrial fields.
| Product Name | Stainless Steel Bar Rod | Flat Bar Size | Customized |
|---|---|---|---|
| Tolerance | ±1% | Length | Customized |
| Certification | ISO 9001 | Round Bar Size | Customized |
| Standard | JIS | Grade | 904L |
| Type | Hexagon | Application | Industry, Construction |
| Delivery Time | 8-14 days | Surface | TSHS |
| Processing Service | Bending, Welding, Decoiling, Punching, Cutting | Package | Standard Package |
904L is a low-carbon, high-alloy super austenitic stainless steel, known for its superior corrosion resistance and comprehensive mechanical properties, which fully complies with JIS standard requirements (JIS G4305, JIS G4303).
- Chromium (Cr): 21.00-23.00% - Enhances oxidation resistance and basic corrosion resistance
- Nickel (Ni): 24.00-26.00% - Improves toughness, ductility and low-temperature performance
- Molybdenum (Mo): 4.00-5.00% - Significantly enhances resistance to chloride ion corrosion
- Copper (Cu): 1.00-2.00% - Improves resistance to dilute sulfuric acid and other weak corrosive media
- Carbon (C): ≤0.02% - Prevents intergranular corrosion, especially after welding
- Tensile Strength (σb): ≥490MPa
- Yield Strength (σ0.2): ≥240MPa
- Elongation (δ5): ≥45%
- Hardness: Brinell Hardness (HB) ≤220, Rockwell Hardness (HRB) ≤95
- Impact Toughness (Akv): ≥60J (room temperature); ≥40J (-196℃)
- Weldability: Excellent weldability with stable post-weld corrosion resistance
The hexagonal cross-section design offers unique structural advantages compared with round rods, especially suitable for industrial construction scenarios requiring stable installation and torque transmission.
- Shape Specification: Standard hexagonal cross-section with uniform side length
- Dimensional Precision: Side length tolerance: ±0.02-±0.05mm, diagonal tolerance: ±0.03-±0.06mm
- Structural Stability: Better torque transmission performance than round rods
- Processing Adaptability: Easy threading, drilling, chamfering and other processing
TSHS surface finish is a high-standard bright polishing surface processed by professional precision polishing technology, with excellent surface quality and practical performance.
- Surface Appearance: Bright as a mirror, uniform luster, no defects
- Surface Roughness: Ra≤0.2μm, ultra-smooth surface
- Corrosion Resistance Enhancement: Forms dense passive film for improved corrosion resistance
- Processing Compatibility: Conducive to welding, painting and electroplating
All products are strictly manufactured, inspected and tested in accordance with JIS standards (JIS G4305: 2015 Stainless Steel Bars, JIS G4303: 2015 Stainless Steel Plates, Sheets and Strips).
- Raw Material Inspection: Chemical composition analysis of qualified 904L stainless steel ingots
- Production Process Control: Strict control of hot rolling, cold drawing, precision straightening, hexagonal forming, TSHS surface polishing
- Finished Product Inspection: Comprehensive inspection including dimensional accuracy, surface quality, mechanical properties, corrosion resistance, and non-destructive testing
- Certification Support: JIS standard certification, mill test certificate (MTC), and relevant test reports
We provide comprehensive customized services to meet diverse industrial construction requirements.
- Size Customization: Side length 5mm-100mm, length 0.5m-12m, custom cross-section shapes
- Surface Finish Customization: TSHS surface, pickled surface, polished surface (400#-1200#), sandblasted surface
- Processing Customization: Threading, drilling, chamfering, bending, welding, precision machining
- Batch Customization: Small-batch (minimum 100kg) and large-batch orders with preferential pricing
- Product Type: 904L Hexagonal Stainless Steel Rod / Bar
- Side Length: 5mm-100mm (standard hot-selling sizes: 5mm, 6mm, 8mm, 10mm, 12mm, 16mm, 20mm)
- Length: 0.5m-12m (standard: 1000mm, 2000mm, 6000mm)
- Surface Finish: TSHS surface (standard), pickled surface, polished surface, sandblasted surface
- Tolerance: Side length ±0.02-±0.05mm, length ±1mm, straightness ≤1.0mm/m
- Packaging: Waterproof plastic film wrapping + wooden box packaging
- Industrial Construction: Structural supports, connecting parts, fasteners, scaffolding accessories, pipeline supports
- Marine Engineering: Coastal industrial buildings, offshore platforms, seawater desalination projects
- Chemical Industry: Corrosion-resistant pipeline supports, reaction vessel accessories, chemical equipment
- High-Temperature Industrial Construction: High-temperature furnace supports, heat exchanger accessories (up to 800℃)
- Other Fields: Precision machinery, electronic equipment, medical equipment, architectural decoration
- Superior 904L super austenitic stainless steel material
- Strict JIS standard compliance with complete certification
- High-quality TSHS surface finish
- Practical hexagonal cross-section for stable installation
- Full customization services for diverse requirements
- Cost-effective factory direct supply
- Long service life in harsh industrial environments
We are committed to providing high-quality, customized 904L hexagonal stainless steel rods/bars that comply with JIS standard and TSHS surface finish for global industrial construction customers. With professional production technology, strict quality control, thoughtful customized services and competitive factory prices, we strive to become your trusted long-term cooperative partner.
