Tube End Forming Machine Taper Pipe Reducing Machine For Reducing Expanding Flanging

Price Negotiable
Price: $4,200-4,500 / set
MOQ: 1 set
Delivery Time: Negotiable
Brand: cedar
Product Description



 Matters needing attention:

1.When the machine is working, it is forbidden to enter its action area.

2.The operator should stand in the range of the emergency stop switch.

3.The unit must be operated exclusively;

4.Turn off the power when the machine is in trouble.

5.Keep the machines and the environment clean;

6.Please turn off the power when installing the mould for safety.

7.To check the oil level of the oil on the oil level before use, and keep the position of the hydraulic oil above 2/3.

8.Place the machine on a solid ground and adjust the level to make the machine more stable.

9.Check the steering of the motor, such as turning the wrong turn and adjusting the wiring.

10.Please confirm the accuracy of the input data when the machine is automatic.

11.When the key is in use, please touch lightly and prohibit the use of hard press.



Model specification

TM40

TM60

TM80

TM100

Maximum applicable pipe fittings

40×2.0MM

60×3MM

80×3.5MM

100*3.5

Maximum working stroke

110MM

120MM

130MM

150MM

Oil output

14Mpa

14Mpa

14Mpa

20Mpa

Work speed

110MM in3-4sec

110MMin3-4sec

110mm in3-4sec

100in3-4sec

Machine size(CM)

200×55×130

2270×150

2490×160

300×120×180

Machine size

4.0 KW

5.5 KW

7.5 KW

11KW

oil pump capacity

19L

23L

29L

33L

Machine weight

about700KG

about1300KG

about2000KG

about26000KG















FAQ

Choose us

   Q: How to quickly choose the most suitable product for you?

   A: You can check it on the product page, or contact customer service at +8618021646346 to tell the following details: What machine do you need? The size, thickness, material, and processing requirements of the workpiece, it is best to have a drawing of the workpiece, and we will provide a more professional machine according to your requirements.

Payment method

   Q: What are your payment terms?

   A: We support T/T, L/C, etc. TT, 30% in advance, and the balance 70% before shipment.

Delivery guarantee

   Q: What is the delivery time?

   A: Usually in stock, if you need to order fixtures and molds, we usually complete it within 7-15 working days. For customized products, please contact customer service to determine the exact time.

Use guarantee

   Q: When I bought this machine, I didn't know how to use it. what do I do?

   A: We will send English manuals, installation and operation videos with the equipment. If you still have questions, we can talk via phone, Whatsapp, WeChat and email.

Quality assurance

   Q: How to ensure quality?

   A: We have factories. We are industry experts and have been operating for more than 10 years. We always adhere to the policy of "high quality, all-round service".

Warranty service

   Q: How long is the warranty period?

   A: Within one year from the date of leaving the factory, if the part fails or is damaged

(Due to quality problems, wearing parts are excluded), our company provides these parts for free.

Company visit

   Q: How do we reach your company?

   A: Our company is located in Zhangjiagang City, Jiangsu Province, near Shanghai. You can fly directly to PVG Airport or Shanghai Hongqiao Airport. Welcome to visit our company.
