PUR-HF D12Y11Y Low Voltage Round Cables PUR Sheathed for Festoon Application 0.6/1kV Plain Copper Conductor

Price Negotiable

Price: 0.1-5

MOQ: 100

Delivery Time: 10 Days

Brand: Minfeng

Product Description

Key attributes

Rated Voltage

0.6/1kv

Size

25-240mm2

Conductor Material

Copper

Insulation Material

Halogen free compound

Working Temperature

90°C

Jacket

Polyurethane, halogen free, flame retardant;

IP Level

Application

Industrial

Rated Current

Type

Low Voltage

Place of Origin

Hebei, China

Model Number

D12Y11Y

Brand Name

Minfeng

Product name

PUR-HF D12Y11Y Low Voltage Round Cables

Standard

DIN EN 60228 / DIN VDE 0295

Conductor

Plain copper, flexible class 5

Insulation

Halogen free compound, based on polyester

Nominal voltage

0.6/1 kV (600/1000V)

Product Description

PUR-HF D12Y11Y Low Voltage Round Cables PUR Sheathed for Festoon Application 0.6/1kV Plain Copper Conductor Application For use as energy and control cable in festoon systems under severe conditions, incl. frequent bending. Also for drag lines, machine tools or materials handling systems.In addition, suitable as drum reeling cable under moderate mechanical stress. Design features Conductor:Plain copper, flexible class 5 acc. to DIN EN 60228 / DIN VDE 0295 Insulation:Halogen free compound, based on polyester Core identification:Up to 5 cores: colored in accordance with DIN VDE 0293-308; From 6 cores: white with black numbers Core arrangement:Cores twisted with short length of lay around central element Outer sheath:Polyurethane, halogen free, flame retardant; Colour: black (opaque) Marking White imprint: FESTOONFLEX PUR-HF -J/-O (number of cores) x (cross-section) (year/week) Electrical parameters Rated voltage:0.6/1 kV (600/1000V) Max. permissible operating voltage AC:0.7/1.2 kV Max. permissible operating voltage DC:0.9/1.8 kV AC Test Voltage:4 kV (5 Min.) Current Carrying Capacity description:Acc. to DIN VDE 0298-4 Chemical parameters Resistance to fire Similar to IEC 60332-1 Water resistance:The cables are suitable for permanent use in water (no drinking water) up to 50 meter diving depth. Thermal parameters Max. permissible temperature at conductor:90 °C Max. short circuit temperature of the conductor 250 °C Ambient temperature for fixed installation:min -50 °C ; max +80 °C Ambient temperature in fully flexible operation:min -40 °C ; max +80 °C Mechanical parameters Max. tensile load on the conductor:15 N/mm² Torsional stress:± 25 °/m Min. bending radius:6 x D (Proved by flexing tests acc. to HD 22.2 part 3.1) Travel speed:- In festoon systems: up to 210 m/min; -For reeling operation: up to 60 m/min; -In chain systems: up to 210 m/min (note: trouble free operation is influenced by several factors, among all the chain length. For long chain system we recommend to operate at lower speed).

Specification

Number of cores x cross section	Conductor diameter max. mm	Outer diameter min. mm	Outer diameter max. mm	Bending radius free moving min. mm	Weight (ca.) kg/km	Permissible tensile force max. N	Conductor resis- tance at 20°C max.	Current carrying capacity for install. free in air (2) A	Short Circuit Current (conduc- tor)
D12Y11Y-O power cables, single core
1x16	5	8.5	9.5	57	170	240	1.21	104	2.29
1x25	6.2	9.9	11.1	67	270	370	0.78	138	3.58
1x35	7.8	11.7	12.9	77	380	520	0.55	170	5.01
1x50	8.9	13.9	15.1	91	530	750	0.39	212	7.15
1x70	11.1	16.2	17.4	104	740	1050	0.27	263	10.01
1x95	12.6	17.9	19.1	115	940	1420	0.21	316	13.59
1x120	14.8	20.2	21.5	130	1200	1800	0.16	370	17.16
1x150	16	21.8	23.2	139	1490	2250	0.13	424	21.45
1x185	17.7	24.3	25.7	154	1830	2770	0.11	484	26.46
1x240	20.2	27.7	29.3	176	2300	3600	0.08	567	34.32
1x300	22.7	30	32	192	3200	4500	0.06	651	42.9
D12Y11Y-O power cables, three core
3x1,5	1.5	6.5	7.5	45	115	60	13.3	24	0.21
3x2,5	2	8.5	9.5	57	130	110	7.98	32	0.36
D12Y11Y-J power cables, four core
4x1,5	1.5	8.1	9.1	55	120	90	13.3	24	0.21
4x2,5	2	9.2	10.2	61	160	150	7.98	32	0.36
4x4	2.6	10.3	11.5	69	230	240	4.95	43	0.57
4x6	3.2	12.1	13.2	80	320	360	3.3	56	0.86
4x10	4	15	16.2	97	520	600	1.91	78	1.43
4x16	5	17.7	18.9	113	750	960	1.21	104	2.29
4x25	6.2	21.1	22.5	135	1160	1500	0.78	138	3.58
4x35	7.8	25.8	27.4	164	1650	2100	0.55	170	5.01
4x50	9.6	31	33	198	2410	3000	0.39	212	7.15
4x70	11.1	38.1	40.6	244	3070	4200	0.27	263	10.01
4x95	12.6	42	44.5	267	4150	5700	0.21	316	13.59
D12Y11Y-J power cables, five core
5x1,5	1.5	8	9	54	150	110	13.3	24	0.21
5x2,5	2	9.8	11	66	180	180	7.98	32	0.36
5x4	2.6	11.6	12.7	77	290	300	4.95	43	0.57
5x6	3.2	14	15.2	91	420	450	3.3	56	0.86
5x10	4	16.2	17.5	105	630	750	1.91	78	1.43
5x16	5	19.4	20.6	124	920	1200	1.21	104	2.29
5x25	6.2	23.2	24.5	148	1380	1870	0.78	138	3.58
D12Y11Y-J Control cables
7x1,5	1.5	9	10	60	220	150	13.3	24	0.21
12x1,5	1.5	14.3	15.5	93	320	270	13.3	24	0.21
18x1,5	1.5	14.5	15.7	94	380	400	13.3	24	0.21
24x1,5	1.5	16.5	17.8	107	500	540	13.3	24	0.21
30x1,5	1.5	19.6	21	126	680	670	13.3	24	0.21
36x1,5	1.5	21.1	22.5	135	770	810	13.3	24	0.21
7x2,5	2	11.5	12.7	76	250	260	7.98	32	0.36
12x2,5	2	16.5	17.7	106	460	450	7.98	32	0.36
18x2,5	2	16.7	17.9	107	580	670	7.98	32	0.36
24x2,5	2	19.2	20.4	122	760	900	7.98	32	0.36
30x2,5	2	24.9	26.5	159	1080	1120	7.98	32	0.36
36x2,5	2	25.9	27.5	165	1300	1350	7.98	32	0.36
