Weatherproof WPC DIY Tiles Co Extrusion High UV Resist Wood Plastic Composite Tiles
Price:
$0.69-1.99or negotiation
MOQ:
200meters per color or negotiation
Delivery Time:
5-7working days
Brand:
Haining Vanshine
Product Description
Weatherproof WPC DIY Tiles Co Extrusion High UV Resist Wood Plastic Composite Tiles
Product Summary
Exclusively engineered to withstand intense solar radiation, hyper-UV indexes, and severe seasonal thermal swings across global regions, these premium Weatherproof WPC DIY Tiles Resist High UV deliver ultimate architectural durability. The composite structure co-extrudes high-density UV absorbers along with non-fading inorganic mineral pigments, combined with a specialized low-deflection polymer alignment that restrains thermal linear expansion to ≤ 0.15%. Resisting fading, warping, and localized joint buckling across extreme seasons, this modular snap-fit layout locks in multi-decade dimensional stability for enterprise procurement projects.
Technical Specifications
| Parameter | Standard Value | Test Method | Verdict |
|---|---|---|---|
| Regular Dimensions | 300mm × 300mm | Tolerance: ±2mm | ✔pass |
| Total Thickness | 22mm | Tolerance: ±1mm | ✔pass |
| Water Absorption Rate | ≤ 1.5% (24h submersion) | EN 317 / GB/T 24508 | ✔pass |
| Flexural Strength | ≥ 20 MPa | ASTM D790 / EN 310 | ✔pass |
| Flexural Modulus | ≥ 1800 MPa | ASTM D790 / EN 310 | ✔pass |
| Impact Resistance | No cracking after 1kg drop from 1m | ASTM D5420 / EN 477 | ✔pass |
| Slip Resistance | R10 - R11 (Wet barefoot area) | DIN 51130 / ASTM F1679 | ✔pass |
| Formaldehyde Emission | E0 | EN 717-1 / GB 18580 | ✔pass |
| Flammability Rating | Bf1 - s1 | EN 13501-1 / ASTM E84 | ✔pass |
Product Features
- Advanced Chromatic Lock Technology Resists Solar Fading
Deployed in high-solar zones, lower-grade tiles quickly lose color purity and develop patchy white drifting due to photo-oxidation. Our outer shield co-extrudes advanced HALS light stabilizers to protect the inorganic mineral pigments at the molecular level. This setup maintains rich color uniformity and permanent shading depth under continuous, raw solar exposure. - Elite Thermal Stability Prevents Grid Buckling Across Seasons
Massive loose-lay tile matrixes face immense physical stress from expanding and contracting between freezing winters and baking summers, causing micro-warping. By dense-packing the virgin polymer crystals, our tiles restrict linear thermal movement to microscopic levels. This engineering ensures the locking layout lines stay balanced, flat, and intact without buckling. - Non-Porous Envelope Shuts Down Freeze-Thaw Splitting
In freezing regions, absorbed moisture expands when turning into ice, tearing apart composite wood fibers from within. Our tiles implement a completely sealed, non-porous outer shell that drives water absorption down to ≤ 0.5%. With moisture tracking blocked, the material permanently eliminates sub-zero frost-cracking, core softening, and cellular rot. - Heat-Resistant Under-Grid Sustains Commercial Deadweight
When surface temperatures soar past 70°C, standard PVC backings soften and collapse under furniture pressure. Our integrated structural grid utilizes a cross-linked heat-resistant polymer, maintaining extreme mechanical stiffness and a deadweight load capacity of ≥ 1500 kg/m². It will not sag or distort, evenly spreading heavy localized weight in hot seasons.
Product Gallery
Available Colors
Our Manufacturing Facility
Frequently Asked Questions
Many outdoor tiles fade quickly and look completely ruined after just one summer. How do your DIY tiles handle intense, direct sunlight?
Cheap composite tiles look old within months because ultraviolet rays break down standard color pigments, causing severe fading and surface whitening. Our Weatherproof WPC DIY Tiles Resist High UV stop this aging process at the ingredient level. We blend premium inorganic mineral pigments with advanced HALS light stabilizers during the co-extrusion process. This chemical armor absorbs and neutralizing UV rays before they can cause damage, locking in the rich, natural wood look for over two decades.
Our project is located in a region with extreme seasonal temperature changes. Won't these interlocking tiles expand and buckle under heavy heat?
No, dimensional stability under extreme temperatures is a core engineering feature of our tiles. Standard retail tiles have high linear expansion rates, meaning they push against each other and pop out of place when the weather gets hot. We use a high-pressure virgin polymer matrix that keeps the linear expansion rate down to ≤ 0.15%. Even when building massive layouts across large commercial terraces, the tiles retain their shape and stay perfectly flat through intense summer heat and freezing winters.
In freezing sub-zero environments, trapped water within composite tiles will freeze and crack the material. How do your tiles prevent this winter damage?
Frost cracking occurs when a tile absorbs water, which then expands as it turns into ice during cold nights, splitting the internal wood fibers. Our engineering design neutralizes this environmental hazard with a 100% non-porous co-extruded shield that drops water absorption to ≤ 0.5%. Since moisture cannot track into the core wood fibers, there is no trapped water to freeze, crack, or weaken the tiles, ensuring flawless performance across severe winter climates.
