John Crane Split Type Mechanical Seal 1800rpm 5.5bar Metal Bellows Seal
John Crane Type 37FS Split Mechanical Seals Elastomer Bellows Seal for Agitators Mixers and Pumps
Cartridge Mechanical Seals
Split Seals
Type 37FS
Heavy-duty Split Elastomer Bellows Seal for Agitators, Mixers and Pumps
The Type 37FS fully split mechanical seal helps significantly reduce maintenance on larger, difficult-to-seal equipment. It is recommended for use on heavy-duty packed equipment that previously could not accommodate mechanical seals due to severe shaft run-out and vibration, difficult disassembly, worn-out equipment and similar problems. Its outside-mounted design allows it to be used on both vertical and horizontal applications.
The mechanical seals are ideal for use on large, heavy duty rotating shaft equipment such as mixers, agitators, and pumps. They are commonly found in the demanding pulp and paper, power generation, food and beverage, wastewater treatment and mining industries and are quickly and easily repairable, either on-site or at any John Crane Service Center.
Features
- The elastomer bellows compression ring provides extreme flexibility. Shaft deflections, angular misalignment, and run-outs are "tracked" by the seal without diminishing performance. Type 37FS split seals solve shaft motion and vibration problems that prohibit use of other seal designs.
- The compression ring acts as the spring, eliminating clogging problems seen in fibrous or abrasive services.
- The wide sealing surface of the sealing ring prevents leaks even on the most worn, pitted shafts.
- Rotating assembly self-aligns itself square with the shaft for true running.
- Fewer parts and simple design allow for easy installation. Seal can be readily mounted on worn shafts and out-of-square stuffing boxes — no modification of equipment is needed.
BESTSEAL — Your Reliable Partner for Mechanical Seals
| BESTSEAL Advantage: | |
|---|---|
| 15 years | Focused in mechanical seal manufacturing |
| 3 hours | Quotation response only takes 3 hours |
| 1 day | Provide production assembly drawings |
| 1 piece | MOQ, One piece can also be produced |
| 15-20 working days | The production cycle only takes 15-20 working days |
| real-time | Real time synchronization of production progress |
BESTSEAL Split Seals
Your Fast-Track Alternative to John Crane Type 37FS
Custom Split Seals — From Drawing to Delivery in 15–20 Working Days
