4 Inch Smart Ventilation Controller with Real Time Monitoring Three Speed Fan WiFi Connectivity
Price:
$65
MOQ:
1
Delivery Time:
2-3 weeks
Brand:
OEM or neutral (no brand)
Product Description
Product overview:
The G6-T fresh air system intelligent controller can monitor indoor temperature, humidity, PM2.5, CO2, and VOC levels in real time; it supports Wi-Fi connectivity; and features a ModBus RTU (RS485) interface, allowing users to connect to smart home and other backend monitoring systems.
The controller controls the fresh air unit's operation and fan speed, and can be widely used in residential, commercial, and industrial settings.
It effectively improves air quality, creating a healthy, comfortable, efficient, environmentally friendly, and energy-saving living and working environment.
Product specifications:
| * Dimension: | 86 × 86 × 40 mm | * Warm-up time: | 2 minutes |
| * Fixing hole distance: | 60mm (standard) | * Response time: | ≤ 10 seconds |
| * Wiring terminal: | Max 2.5 mm2 wire | * Recovery time: | ≤ 30 seconds |
| * Rated voltage: | AC110-240V, 50/60Hz | * Operating temperature: | -10℃--- +50℃ |
| * Standby Power: | ≤ 2.0W | * Operating humidity: | 5％RH——90％RH |
| * Control power: | ≤ 200W | * Storage temperature: | -10℃--- +60℃ |
| * Suitable for fans: | AC/EC/DC | * Storage humidity: | ≤ 60％RH |
| * Temperature display range: | 0℃ —— 99℃ | * Life: | ≥ 3 years |
| * CO2 display range: | 350ppm——2000ppm | * PM2.5 display range: | 1ug/m3——999ug/m3 |
Products images:
