Xy-1A 150m Depth Geological Drilling Rig Personal Portable
It is a high-speed portable drilling rig featuring oil pressure feeding. This mechanically transmitted, oil pressure-fed portable drilling rig offers compact dimensions and lightweight construction for enhanced mobility and operational efficiency.
| Drill Rig Details | Swivel Head | ||
|---|---|---|---|
| Drilling depth | Max. 150m | Spindle speed | 1010, 790, 470, 295, 140 (r/min) |
| Hole diameter | Max. 150mm | Spindle stroke | 450mm |
| Drill rod diameter | 42mm | Spindle pull-down | Max. 15KN |
| Angle range | 90-75° | Spindle lifting capacity | Max. 25KN |
| Oil Pump | Water Pump | ||
|---|---|---|---|
| Model | YBC-12/125 | Model | Horizontal reciprocating single-acting piston pump |
| Rated pressure | 12.5Mpa | Working pressure | Max. 1.25Mpa |
| Flow speed | 8ml/r | ||
| Rated speed | 1500r/min | ||
| Hoist | Power (Diesel) | ||
|---|---|---|---|
| Max. lifting capacity | 15KN | Model (diesel engine) | ZS1105 |
| Hoisting drum revolution | 121, 76, 36 (r/min) | Rated power | 12.1KW |
| Drum diameter | 140mm | Rated speed | 2200r/m |
| Weight | Around 600kg | Size | 1620 × 970 × 1560mm |
- General survey and exploration of solid deposits and engineering geological survey
- Inspection holes of various concrete structures
- Diamond, alloy and steel bits can be selected for drilling according to different strata
