Original M12 Proximity Sensor BALLUFF BES M12MI-PSC40B-S04G

BES 516-324-S49-C is M8 threaded cylindrical inductive proximity sensor manufactured by Balluff Germany. It features 1.5mm flush sensing distance, PNP normally open output, M8 3-pin male connector, stainless steel housing with IP68 high protection grade. Built-in reverse polarity & short-circuit protection, widely applied for tiny metal part position detection on precision automation equipment.

• Sensing Distance: 1.5 mm (Shielded Flush Mount)
• Output Mode: PNP Normally Open (NO)
• Supply Voltage: 10 ~ 30 VDC
• Connection: M8*1 Male Plug, 3-pin
• Protection Class: IP68
• Housing: Stainless Steel, M8*1 Thread
• Dimension: Φ8 * 55 mm
• Operating Temp: -40℃ ~ +85℃
• Max Switching Current: 200mA
• Switching Frequency: 3000Hz
• Certifications: CE, cULus, UKCA, EAC

• Machine Building & Automation:

  Control of packaging machines, textile machinery, machine tools, and electronic manufacturing equipment.

• Robotics & Handling:

  Positioning control for small manipulators, conveyor systems, and automated assembly lines.

• Process Industry:

  Sequence control for pumps, valves, and production lines in food, chemical, and pharmaceutical plants.

• Energy & Utilities:

  Monitoring and control of auxiliary equipment, HVAC systems, and small-scale automation units.

• Logistics & Warehousing:

  Control of sorting equipment, material handling systems, and automated storage systems.

It supports DIN rail mounting and Ethernet communication, suitable for compact automation and networking applications.
