FESTO Solenoid valve CPE18-M1H-3OLS-1/4 163144 GTIN4052568133092 Pneumatic Solenoid Valves
Price:
EXW USD60-80
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO Solenoid valve CPE18-M1H-3OLS-1/4 163144 GTIN4052568133092 Pneumatic Solenoid Valves
About product
1.Universal individual valve.
2.High flow rate relative to its size.
3.Simple manifold design consisting of fixed-grid manifold blocks made from stable aluminium with 2 to 10 valve positions or modular manifold blocks made from durable polymer.
Technical Data
| Valve function | 3/2 open, single solenoid |
| Type of actuation | Electric |
| Construction width | 18 mm |
| Standard nominal flow rate | 1700 l/min |
| pneumatic working port | G1/4 |
| Operating voltage | 24V DC |
| Design | Piston gate valve |
| Type of reset | Pneumatic spring |
| Degree of protection | IP65 With plug socket To IEC 60529 |
| Nominal size | 8 mm |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting via accessory Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | External |
| Flow direction | Non-reversible |
| Symbol | 00991402 |
| Valve position code | Inscription label holder |
| lap | Positive overlap |
| Switching time off | 18 ms |
| Switching time on | 28 ms |
| Duty cycle | 100% |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5°C-50°C |
| Ambient temperature | -5°C-50°C |
| Product weight | 150 g |
| Electrical connection | Type C |
| Type of mounting | With through-hole |
| Pilot exhaust port 82 | M5 |
| Pilot air port 12 | M5 |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Pneumatic connection, port 3 | G1/4 |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
Another size as below
| Type | Order no | Price |
| CPE18-M1H-3GL-1/4 | 163141 | USD60-80 |
| CPE18-M1H-3GL-QS-8 | 163149 | USD60-80 |
| CPE18-M1H-3GL-QS-10 | 163157 | USD60-80 |
| CPE18-M2H-3GL-1/4 | 163761 | USD60-80 |
| CPE18-M2H-3GL-QS-8 | 163769 | USD60-80 |
| CPE18-M2H-3GL-QS-10 | 163777 | USD60-80 |
| CPE18-M3H-3GL-1/4 | 163785 | USD60-80 |
| CPE18-M3H-3GL-QS-8 | 163793 | USD60-80 |
| CPE18-M3H-3GL-QS-10 | 163801 | USD60-80 |
| CPE18-M1H-3OL-1/4 | 163140 | USD60-80 |
| CPE18-M1H-3OL-QS-8 | 163148 | USD60-80 |
| CPE18-M1H-3OL-QS-10 | 163156 | USD60-80 |
| CPE18-M2H-3OL-1/4 | 163760 | USD60-80 |
| CPE18-M2H-3OL-QS-8 | 163768 | USD60-80 |
| CPE18-M2H-3OL-QS-10 | 163776 | USD60-80 |
| CPE18-M3H-3OL-1/4 | 163784 | USD60-80 |
| CPE18-M3H-3OL-QS-8 | 163792 | USD60-80 |
| CPE18-M3H-3OL-QS-10 | 163800 | USD60-80 |
| CPE18-M1H-3GLS-1/4 | 163145 | USD60-80 |
| CPE18-M1H-3GLS-QS-8 | 163153 | USD60-80 |
| CPE18-M1H-3GLS-QS-10 | 163161 | USD60-80 |
| CPE18-M2H-3GLS-1/4 | 163765 | USD60-80 |
| CPE18-M2H-3GLS-QS-8 | 163773 | USD60-80 |
| CPE18-M2H-3GLS-QS-10 | 163781 | USD60-80 |
| CPE18-M3H-3GLS-1/4 | 163789 | USD60-80 |
| CPE18-M3H-3GLS-QS-8 | 163797 | USD60-80 |
| CPE18-M3H-3GLS-QS-10 | 163805 | USD60-80 |
| CPE18-M1H-3OLS-1/4 | 163144 | USD60-80 |
| CPE18-M1H-3OLS-QS-8 | 163152 | USD60-80 |
| CPE18-M1H-3OLS-QS-10 | 163160 | USD60-80 |
| CPE18-M2H-3OLS-1/4 | 163764 | USD60-80 |
| CPE18-M2H-3OLS-QS-8 | 163772 | USD60-80 |
| CPE18-M2H-3OLS-QS-10 | 163780 | USD60-80 |
| CPE18-M3H-3OLS-1/4 | 163788 | USD60-80 |
| 6 CPE18-M3H-3OLS-QS-8 | 163796 | USD60-80 |
| CPE18-M3H-3OLS-QS-10 | 163804 | USD60-80 |
Sectional view
There are so many models and series. Welcome to enquire!
