FESTO One Way Flow Control Valve GRA-1/4-B 6509 GTIN4052568001247
Price:
USD40-50
MOQ:
1pc
Delivery Time:
5-7 working days
Brand:
FESTO
Product Description
FESTO One-way flow control valve GRA-1/4-B 6509 GTIN4052568001247
About product
1.Non-return and flow control valve.
2.In-line installation.
3.Valve function:One-way flow control function.
4.Adjusting element:Knurled screw.
5.Type of mounting:Through-hole,Front panel mounting.
6.Note on the operating/ pilot medium:Lubricated operation possible (in which case lubricated operation will always be required).
Product Technical Data
| Valve function | One-way flow control function |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Adjustment component | Knurled screw |
| Type of mounting | Either: Front panel mounting With through-hole |
| Standard nominal flow rate in flow control direction | 420 l/min |
| Standard nominal flow rate in blocked direction | 780 l/min |
| Operating pressure | 0.1 bar ... 10 bar |
| Material housing | Die-cast zinc |
| Mounting position | optional |
| Symbol | 00991453 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 180 g |
| Note on materials | RoHS-compliant |
| Material adjusting screw | Brass |
Product package
There are many specifications , price and delivery time. Welcome to inquire.
