52 Mm Pneumatic Solenoid Valves MFH-3-1/2 9857 GTIN4052568002046

Price Negotiable

Price: EXW USD80-100

MOQ: 1pc

Delivery Time: 5-7 working days

Brand: FESTO

Product Description

FESTO Solenoid valve MFH-3-1/2 9857 GTIN4052568002046 Pneumatic Solenoid Valves

About product

1.Robust structure and reliable performance.

2.Specific type according to ATEX directive, which can be used in the workplace with potential explosion hazard.

3.Very sturdy poppet valve concept for all 3/2 and 5/2-way valves.

4.Pneumatic or electrical actuation with F solenoid coil.

5.With flow rates of up to 7500 l/min.

6.Solenoid coil can be easily exchanged later.

7.Solenoid coil not included in scope of delivery.

Technical Data

Valve function	3/2-way, closed, monostable
Type of actuation	Electric
Construction width	52 mm
Standard nominal flow rate	3700 l/min
pneumatic working port	G1/2
Operating voltage	Via solenoid coil, must be ordered separately
Operating pressure	0.15 MPa ... 0.8 MPa
Operating pressure	1.5 bar ... 8 bar
Design	Poppet seat
Type of reset	Mechanical spring
Approval	c UL us - Recognized (OL)
Degree of protection	IP65
Nominal size	14 mm
Grid dimension	69 mm
Exhaust-air function	With flow control option
Sealing principle	Soft
Mounting position	optional
Manual override	Detenting
Type of piloting	Pilot actuated
Flow direction	Non-reversible
Symbol	00991041
lap	Underlap
b value	0.3
Switching time off	90 ms
Switching time on	18 ms
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Product weight	1100 g
Electrical connection	Via F coil, to be ordered separately
Type of mounting	Either: On manifold rail With through-hole
Pilot exhaust port 82	M5
Pneumatic connection, port 1	G1/2
Pneumatic connection, port 2	G1/2
Pneumatic connection, port 3	G1/2
Note on materials	RoHS-compliant
Material seals	NBR
Material housing	Die-cast aluminium
