DGC-12-600 - G-P-A 530907 Pneumatic Air Cylinders FESTO Linear Drive
Price:
EXW USD300-400
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Linear drive DGC-12-600 - G-P-A 530907 Pneumatic Air Cylinders
About product
Basic design, plain or ball bearing guide, guide axis without actuator
All settings accessible from one side
Available with variable end stops and intermediate position module
Compact – installation length relative to stroke
Loads and devices can be directly mounted on the slide
Long strokes with no restrictions
Virtually no leakage
Technical Data
| Piston diameter | 12 mm |
| Mounting position | optional |
| Guide | Basic guide Recirculating ball bearing guide |
| Position detection | Via proximity switch |
| Operating pressure | 0.25 MPa ... 0.8 MPa |
| Operating pressure | 2.5 bar ... 8 bar |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Type of mounting | With accessories |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | POM TPE-U(PU) |
Package picture
