FESTO One Way Flow Control Valve GRLA-M3 175038 GTIN4052568037628

Price Negotiable

Price: EXW USD15-25

MOQ: 1pc

Delivery Time: 5-7working days

Brand: FESTO

Product Description

FESTO One-way flow control valve GRLA-M3 175038 GTIN4052568037628

About product

1.Functional combination of one-way flow control valve and piloted check valve.

2.Flow control valve, flow control at one end.

3.Polymer, metal or stainless steel design.

4.The piston speed of both advancing and retracting pneumatic cylinders can be regulated using one-way flow control valves.

5.This is done through suitable restriction of the flow rate of compressed air in exhaust air or supply air direction. The non-return function works in the opposite direction.

6.The flow control function creates an adjustable annular gap inside the valve. This gap can be increased or decreased by turning the knurled screw or slotted head screw.

7.The required restriction can be set with the help of this adjustment element.

Technical Data

Valve function	Exhaust air one-way flow control function
Pneumatic connection, port 1	M3
Pneumatic connection, port 2	M3
Adjustment component	Slotted head screw
Type of mounting	Screw-in
Standard nominal flow rate in flow control direction	18 l/min
Standard nominal flow rate in blocked direction	18 l/min ... 20 l/min
Operating pressure	0.2 bar ... 10 bar
Ambient temperature-	-10°C-60°C
Mounting position	optional
Symbol	00991452
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Media temperature	-10°C-60°C
Max. tightening torque	0.3 Nm
Product weight	2 g
Material screw-in stud	Brass Nickel-plated
Note on materials	RoHS-compliant
Material seals	NBR
Material adjusting screw	Brass
Material swivel fitting	Die-cast zinc
