FESTO Push In T Connector NPQH-T-Q14-E-P10 578385 GTIN4052568060886
Price:
EXW USD8-10
MOQ:
1 PCS
Delivery Time:
5-7 working days
Brand:
FESTO
Product Description
FESTO Push-in T-connector NPQH-T-Q14-E-P10 578385 GTIN4052568060886
About product
1.Rotatable 360°.
2.Male thread with external hex.
3.Highly resistant to temperatures and pressure.
4.Solid-metal brass, chemically nickel-plated.
5.High corrosion and chemical resistance.
Product Technical Data
| Size | Standard |
| Nominal size | 12 mm |
| Mounting position | optional |
| Design | T-shape |
| Size of pack | 10 |
| Design | Push-pull principle |
| Certificate issuing authority | NSF C0523185 |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 4 according to ISO 14644-1 |
| Ambient temperature | 0°C-150°C |
| Product weight | 79.9 g |
| Pneumatic connection, port 1 | For tubing outer diameter of 14 mm |
| Pneumatic connection, port 2 | For tubing outside diameter of 14 mm |
| Note on materials | RoHS-compliant |
| Material housing | Brass, chemically nickel-plated |
| Material release ring | Brass, chemically nickel-plated |
| Material tubing seal | FPM |
| Material tubing clamp component |
High-alloy stainless steel |
Dimensions and ordering data
There are many specifications of connectors, price and delivery time. Welcome to inquire.
