FESTO Proximity Sensor SIEN-M5B-PS-S-L 150371 GTIN4052568068813
Price:
EXW USD20-30
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Proximity sensor SIEN-M5B-PS-S-L 150371 GTIN4052568068813
About product
3-wire cable, 2.5 m long
Active surface
1 switching status indication, yellow
With standard switching
For DC voltage
Round design
Technical Data
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991701 |
| Approval | RCM trademark c UL us listed (OL) |
| CE mark (see declaration of conformity) | To EU EMC Directive |
| Note on materials | RoHS-compliant |
| Rated operating distance | 0.8 mm |
| Ambient temperature | -25°C-70°C |
| Switching output | PNP |
| Switching element function | N/O contact |
| Max. switching frequency | 5000 Hz |
| Max. output current | 200 mA |
| Short circuit current rating | Pulsed |
| Operational voltage range DC | 10 V ... 30 V |
| Reverse polarity protection | For all electrical connections |
| Electrical connection | 3-pin M8x1 Plugs |
| Size | M5x0.5 |
| Tightening torque | 1.5 Nm |
| Mounting type | Flush |
| Product weight | 4.3 g |
| Material housing | PA High-alloy stainless steel |
| Switching status indication | Yellow LED |
| Ambient temperature with moving cable | -5°C-70°C |
| Degree of protection | IP67 |
| Immunity to surge | 1 kV |
| Corrosion resistance class CRC | 4 - Very high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Additional information for sensor selection | with standard sensing distance |
| Electrical output | PNP |
| Selection of sensor design | Standard |
Dimensions – M5
There are many models . Please hurry to me!
