FESTO Guided Drive Pneumatic Air Cylinders DFM-12- 160-B -P-A-GF 529119
Price:
EXW USD100-120
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Guided drive DFM-12- 160-B -P-A-GF 529119
About product
1.Good protection against torsion.
2.High rigidity.
3.Maintenance-free.
4.Wide range of mounting options.
5.Arge-diameter guide rods and four plain-bearing bushes.
Technical Data
| Stroke | 160mm |
| Piston diameter | 12 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Guide | Plain-bearing guide Recirculating ball bearing guide |
| Design | Guidance |
| Position detection | Via proximity switch |
| Operating pressure | 0.2 MPa ... 1 MPa |
| Operating pressure | 2 bar ... 10 bar |
| Mode of operation | Double-acting |
| ATEX category gas | II 2G |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 0 - No corrosion stress 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | NBR |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Mounting options
A wide range of products with excellent prices. Please contact me!
