FESTO Compact Cylinder ADN-32-40-I-P-A 536284 GTIN4052568087814

Name: FESTO Compact Cylinder ADN-32-40-I-P-A 536284 GTIN4052568087814
Brand: Airwolf Automation

Price Negotiable

Price: EXW USD30-50

MOQ: 1pc

Delivery Time: 7-10working days

Brand: FESTO

Product Description

FESTO Compact cylinder ADN-32-40-I-P-A 536284 GTIN4052568087814

About product

1.Easy to mount with a comprehensive range of mounting accessories for just about every type of installation.

2.Highly flexible thanks to the wide range of variants.

3.Contactless position sensing using proximity switches.

4.Optimised manufacturing methods, patented technology and more than 40 years of experience in the field of cylinders make Festo and ADN/AEN a great partner.

5.Integrated cushioning for absorbing residual energy.

6.Long service life thanks to exceptional cushioning characteristics and low friction values.

Technical Data

Stroke	40 mm
Piston diameter	32 mm
Piston rod thread	M8
Cushioning	Elastic cushioning rings/plates at both ends
Mounting position	optional
Conforms to standard	ISO 21287
Piston-rod end	Female thread
Position detection	Via proximity switch
Symbol	00991217
Variants	Piston rod at one end
Operating pressure	0.06 MPa ... 1 MPa
Operating pressure	0.6 bar ... 10 bar
Mode of operation	Double-acting
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Cleanroom class	Class 6 according to ISO 14644-1
Ambient temperature	-20°C-80°C
Basic weight for 0 mm stroke	265 g
Pneumatic connection	G1/8
Note on materials	RoHS-compliant
Material collar screws	Steel
Material cover	Anodised wrought aluminium alloy
Material seals	TPE-U(PUR)
Material piston rod	High-alloy steel
Material cylinder barrel	Smooth-anodised wrought aluminium alloy
