Festo ISO Cylinder DSNU-25-25-PPV-A 33975 GTIN4052568009762
Price:
EXW USD20-30
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO ISO cylinder DSNU-25-25-PPV-A 33975 GTIN4052568009762
About product
1.Good running performance and long service life.
2.Extensive range of accessories makes it possible to install the cylinder virtually anywhere.
3.The basic versions conform to ISO 6432, variants are based on these standards.
Technical Data
| Stroke | 25 mm |
| Piston diameter | 25 mm |
| Piston rod thread | M10x1.25 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | CETOP RP 52 P ISO 6432 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Cylinder barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Ambient temperature | -20 °C ... 80 °C |
| Cushioning length | 17 mm |
| Basic weight for 0 mm stroke | 238 g |
| Additional weight per 10 mm stroke | 11 g |
| Type of mounting | With accessories |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy Colourless anodised |
| Material seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy stainless steel |
| Material cylinder barrel | High-alloy stainless steel |
General technical data
A wide range of products with excellent prices. Please contact me!
