546702 Pneumatic Solenoid Valves FESTO VSVA-B-M52-MH-A1-1C1 GTIN4052568184865
Price:
EXW USD100-150
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO Solenoid valve VSVA-B-M52-MH-A1-1C1 546702 GTIN4052568184865
About product
1.Conversions and extensions are possible at any time.
2.High-performance valves in a sturdy metal housing.
3.Individual electrical connection via square or round plug sockets.
Technical Data
| Valve function | 5/2-way, monostable |
| Type of actuation | Electric |
| Valve size | 26 mm |
| Operating voltage | 24V DC |
| Type of reset | Mechanical spring |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP65 NEMA 4 |
| Nominal size | 9 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Conforms to standard | ISO 15407-1 VDMA 24563 |
| Manual override | Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Flow direction | Non-reversible |
| Symbol | 00991003 |
| lap | Positive overlap |
| Signal status display | LED |
| Characteristic coil data | 24 V DC: 1.8 W |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5°C-50°C |
| Ambient temperature | -5°C-50°C |
| Product weight | 180 g |
| Type of mounting | On sub-base |
| Pilot exhaust port 82/84 | Ducted Not ducted as per standard |
| Pneumatic connection, port 4 | Sub-base size 26 mm to ISO 15407-1 |
| Pneumatic connection, port 5 | Sub-base size 26 mm to ISO 15407-1 |
| Pilot control interface | To ISO 15218 |
| Note on materials | RoHS-compliant |
Package picture
There are many styles and types, welcome to enquire!
