FESTO ISO Cylinder DSBC-32-25-PPVA-N3 1376422 GTIN4052568016555

Name: FESTO ISO Cylinder DSBC-32-25-PPVA-N3 1376422 GTIN4052568016555
Brand: Airwolf Automation

Price Negotiable

Price: EXW USD40-50

MOQ: 1pc

Delivery Time: 10-15 working days

Brand: FESTO

Product Description

FESTO ISO cylinder DSBC-32-25-PPVA-N3 1376422 GTIN4052568016555

About product

1.Double-acting.

2.For contactless position sensing.

3.Optionally with protection against rotation.

4.Extensive range of accessories makes it possible to install the cylinder virtually anywhere.

5.The variants can be configured according to individual needs using a modular product system.

6.Wide range of variants provides high level of flexibility.

Technical Data

Stroke	25 mm
Piston diameter	32 mm
Piston rod thread	M10x1.25
Cushioning	Pneumatic cushioning, adjustable at both ends
Mounting position	optional
Conforms to standard	ISO 15552
Piston-rod end	Male thread
Design	Piston Piston rod Profile barrel
Position detection	Via proximity switch
Symbol	00991235
Variants	Piston rod at one end
Mode of operation	Double-acting
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20 °C ... 80 °C
Cushioning length	17 mm
Basic weight for 0 mm stroke	465 g
Additional weight per 10 mm stroke	27 g
Pneumatic connection	G1/8
Note on materials	RoHS-compliant
Material cover	Die-cast aluminium, coated
Material piston seal	TPE-U(PU)
Material piston	Wrought aluminium alloy
Material piston rod	High-alloy steel
Material piston rod wiper	TPE-U(PU)
Buffer seal material	TPE-U(PU)
Cushioning piston material	POM
Material cylinder barrel	Smooth-anodised wrought aluminium alloy
Material nut	Galvanised steel
Material bearing	POM
Material collar screws	Galvanised steel
