FESTO ISO Cylinder DNC-100-160-PPV-A 163471 GTIN4052568134730
Price:
EXW USD200-300
MOQ:
1pc
Delivery Time:
10-12 working days
Brand:
FESTO
Product Description
FESTO ISO cylinder DNC-100-160-PPV-A 163471 GTIN4052568134730
About product
Conforms to standard:ISO 15552
Piston-rod end:Male thread
Cushioning length:32 mm
Moving mass for 0 mm stroke:1544 g
Material cover:Die-cast aluminium Coated
Technical Data
| Stroke | 160 mm |
| Piston diameter | 100 mm |
| Piston rod thread | M20x1.5 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 15552 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Cushioning length | 32 mm |
| Moving mass for 0 mm stroke | 1544 g |
| Additional moving mass per 10 mm stroke | 38 g |
| Type of mounting | Via female thread With accessories |
| Pneumatic connection | G1/2 |
| Note on materials | RoHS-compliant |
| Material cover | Die-cast aluminium Coated |
| Material seals | TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy Smooth anodised |
General technical data
