DSBC-63-160-PPVA-N3 FESTO ISO Cylinder 1383584 GTIN4052568232191

Name: DSBC-63-160-PPVA-N3 FESTO ISO Cylinder 1383584 GTIN4052568232191
Brand: Airwolf Automation

Price Negotiable

Price: EXW USD200-300

MOQ: 1pc

Delivery Time: 10-15 working days

Brand: FESTO

Product Description

FESTO ISO cylinder DSBC-63-160-PPVA-N3 1383584,GTIN4052568232191

About product

Piston rod thread:M16x1.5

Stroke:160 mm

Piston diameter:63 mm

Conforms to standard:ISO 15552

Corrosion resistance class CRC:2 - Moderate corrosion stress

Technical Data

Stroke	160 mm
Piston diameter	63 mm
Piston rod thread	M16x1.5
Cushioning	Pneumatic cushioning, adjustable at both ends
Mounting position	optional
Conforms to standard	ISO 15552
Piston-rod end	Male thread
Design	Piston Piston rod Profile barrel
Position detection	Via proximity switch
Symbol	00991235
Variants	Piston rod at one end
Mode of operation	Double-acting
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20°C-80°C
Cushioning length	22 mm
Basic weight for 0 mm stroke	1740 g
Additional weight per 10 mm stroke	62 g
Pneumatic connection	G3/8
Note on materials	RoHS-compliant
Material cover	Die-cast aluminium, coated
Material piston seal	TPE-U(PU)
Material piston	Wrought aluminium alloy
Material piston rod	High-alloy steel
Material piston rod wiper	TPE-U(PU)
Buffer seal material	TPE-U(PU)
Cushioning piston material	POM
Material cylinder barrel	Smooth-anodised wrought aluminium alloy
Material nut	Galvanised steel
Material bearing	POM
Material collar screws	Galvanised steel
