Silver FESTO Compact Cylinder ADVU-50-50-A-P-A 156642 Pneumatic Air Cylinders
Price:
EXW USD50-70
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO Compact cylinder ADVU-50-50-A-P-A 156642 Pneumatic Air Cylinders
About product
Stroke:50 mm
Piston diameter:50 mm
Color:Silver
Mode of operation:Double-acting
Corrosion resistance class CRC:2 - Moderate corrosion stress
Technical Data
| Stroke | 50 mm |
| Piston diameter | 50 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Piston-rod end | Male thread |
| Design | Piston Piston rod |
| Position detection | Via proximity switch |
| Symbol | 00991217 |
| Variants | Piston rod at one end |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Basic weight for 0 mm stroke | 560 g |
| Additional weight per 10 mm stroke | 72 g |
| Type of mounting | Either: With through-hole With accessories |
| Pneumatic connection | G1/8 |
| Material collar screws | Galvanised steel |
| Material cover | Wrought aluminium alloy |
| Material dynamic seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy |
Dimensions – Basic cylinder
There are so many kinds. Please contact with me!
