Professional YTC type Pneumatic Valve Actuator Accessory Aluminium Booster Relay YT-300 YT-320 YT-310 Volume Boost
Professional YTC type Pneumatic Valve Actuator Accessory Aluminium Booster Relay YT-300 YT-320 YT-310 Volume Boost
Volume booster YT-300, YT-310 and YT-320 boost the valve function's reaction speed by providing large air flow rate to actor actuator.
1. Improves speed of valve movement
2. Improves stability with by-pass control
3. Reacts sudden change in supply pressure
4. Fixed deadand due to the seat-to-seat type of supply and exhaust pressure
Specifications:
| Item, Type | YT-300 | YT-320 | YT-310 | ||
| YT-305 | YT-325 | YT-315 | |||
| Max. Supply Pressure | 1MPa (10bar) | ||||
| Max. Signal/Output | 0.7MPa | ||||
| Signal/Output Pressure Ratio | 1:1 | ||||
| Flow Capacity (Cv) | exhaust | 1.32 | 2.08 | 5.29 | |
| output | 1.19 | 2.72 | 4.91 | ||
| Supply/Output Connection | PT(NPT)1/4 | NPT 1/2 | NPT 3/4 | ||
| Signal Connection | PT (NPT)1/4 | NPT 1/4 | |||
| Linearity | ±1% F.S. | ||||
| Ambient Temp. | -20~70℃ | ||||
| Material | YT-300, YT-320,YT-310 | Aluminium Diecasting | |||
| YT-305, YT-325,YT-315 | Stainless Steel 316 | ||||
| Weight: kg | 0.50 | 0.76 | 2.30 | ||
| 1.30 | 1.90 | 5.00 | |||
Drawings:
1. YT-300
2. YT-320
3. YT-310
Pictures details:
