DAB Stainless Steel Slim Pneumatic Air Cylinder With Squareness Cover
DAB Stainless Steel Slim Pneumatic Air Cylinder With Squareness Cover
Airtac type stainless steel slim DAB double acting Pneumatic air cylinder with squareness cover Bore size 16mm-40mm e.g. DAB-25-100-2-S with magnet and Rubber buffer
Quick Detail:
* Airtac equvalent stainless steel slim air cylinder with squareness cover
* Mounting model side mounting and face mounting for option,Mounting accessories foot type,flange type,Single U type.
* With magnet, rubber cushion keep from impact,long service life,lower noise
* Adjustable air cushion for bore size 50mm and 63mm
* Stainless steel barrel for anti-corresion and sanitary application
* Piston rod #45(ASTM-1045) steel chrome-plated
* Stainless steel piston rod is available
* With self-lubricating bearing,lubrication free
* Bore size 16mm,20mm,25mm,32mm,40mm,50mm,63mm
Specifications:
|
ORDERING CODE |
||||
|
DAB |
25 |
100 |
2 |
S |
|
DAB:Stainless steel slim cylinder double action with squareness cover |
Bore Size |
Stroke |
Mounting type |
S:With magnet |
|
16:16mm |
2:Side mounting |
|||
|
20:20mm |
||||
|
25:25mm |
||||
|
32:32mm |
4:Face mounting |
Blank: Without magnet |
||
|
40:40mm |
||||
|
50:50mm |
||||
|
63:63mm |
||||
|
SPECIFICATION |
|||||||
|
Bore size(mm) |
16 |
20 |
25 |
32 |
40 |
50 |
63 |
|
working Medium |
Filtered compressed air |
||||||
|
Motion Pattern |
Double action |
||||||
|
Pressure Endurance |
1.32MPa |
1.03MPa |
|||||
|
Operating pressure range |
0.04~0.9MPa |
0.06~0.7MPa |
|||||
|
Ambient Temperature |
-0~70ºC |
||||||
|
Buffer cushioning |
Rubber cushion |
Air cushion adjustable |
|||||
|
Operating Speed |
30~700mm/s |
30~500mm/s |
|||||
|
Port size |
Rc1/8 |
Rc1/8 |
Rc1/8 |
Rc1/8 |
Rc1/8 |
Rc1/4 |
Rc1/4 |
|
Bore size |
C |
E |
G |
H |
I |
J |
K |
M |
R |
S |
U |
|
20 |
53 |
23 |
28 |
15 |
12 |
5 |
M8x1 |
17 |
10 |
5 |
21.4 |
|
25 |
53 |
26 |
30 |
18 |
14 |
6 |
M10x1.25 |
19 |
10 |
5 |
26.4 |
|
32 |
54 |
31 |
36 |
23 |
14 |
6 |
M10x1.25 |
22 |
11 |
6 |
33.6 |
|
40 |
60 |
31 |
44 |
23 |
19 |
8 |
M14x1.5 |
22 |
13 |
6 |
41.6 |
|
Bore size |
V |
W |
AA |
AB |
AD |
AE |
AF |
AH |
AI |
AN |
AP |
|
20 |
8 |
6 |
104 |
34 |
11 |
38 |
22 |
28 |
14 |
9 |
Ø6.6 Ø11 Depth 6.5 |
|
25 |
10 |
8 |
109 |
38 |
12 |
42 |
26 |
30 |
15 |
10 |
Ø6.6 Ø11 Depth 6.5 |
|
32 |
12 |
10 |
121 |
45 |
14 |
54 |
34 |
36 |
18 |
14 |
Ø9.2 Ø14 Depth 8.5 |
|
40 |
16 |
14 |
135 |
48 |
17 |
68 |
46 |
44 |
22 |
19 |
Ø11.2 Ø17.5 Depth 11 |
|
Bore size |
E |
F |
H |
I |
J |
K |
M |
R |
S |
U |
|
20 |
23 |
12 |
15 |
12 |
5 |
M8x1 |
17 |
10 |
5 |
21.4 |
|
25 |
26 |
14 |
18 |
14 |
6 |
M10x1.25 |
19 |
10 |
5 |
26.4 |
|
32 |
31 |
14 |
23 |
14 |
6 |
M10x1.25 |
22 |
11 |
6 |
33.6 |
|
40 |
31 |
14 |
23 |
19 |
8 |
M14x1.5 |
22 |
13 |
6 |
41.6 |
|
Bore size |
V |
W |
BS |
BB |
BC |
BD |
BE |
BF |
BP |
BU |
|
20 |
8 |
6 |
104 |
35 |
28 |
18 |
38 |
28 |
5.5 |
22 |
|
25 |
10 |
8 |
109 |
40 |
30 |
20 |
42 |
32 |
5.5 |
24 |
|
32 |
12 |
10 |
121 |
45 |
36 |
24 |
54 |
42 |
5.6 |
28 |
|
40 |
14 |
14 |
135 |
45 |
44 |
28 |
68 |
52 |
9 |
34 |
