3 Position 4 Way Pneumatic Manual Directional Control Hand Switching Valve G1/4"~G1/2"
3 Position 4 Way Pneumatic Manual Directional Control Hand Switching Valve G1/4"~G1/2"
HV Series Three position four way hand switching valve port size G1/4,G3/8,G1/2 e.g HV-02 Various handler for option
Quick Detail:
* HV Series hand switching valve
* Three position Four Way
* Port Size G1/4,G3/8,G1/2
* Various handler shape selectable
* Switching angle 90º,sensitive repond acting
* Smooth switching,Long service life
Applications:
HV series hand switching valve manual operated use for fast direction change of anywhere and anytime necessary function required by manual operating,Due to easy and flexible operating,it was widely use in the Pneumatic system
Specifications:
|
ORDERING CODE |
|
|
HV |
02 |
|
Type |
Port Size |
|
HV:HV Series Three Position Four way Hand Switching Valve |
02:G1/4" |
|
03:G3/8" |
|
|
04:G1/2" |
|
|
SPECIFICATION |
|||
|
Model no |
HV-02 |
HV-03 |
HV-04 |
|
Working Medium |
Compressed 40 Micron Filtered Air |
||
|
Body Material |
Aluminum Alloy |
||
|
Position And Way Numbers |
Three Position Four Way |
||
|
Port Size |
G1/4" |
G3/8" |
G1/2" |
|
Motion Pattern |
Direct Acting |
||
|
Working Pressure |
0~0.8MPa |
||
|
Switching Angle |
90º |
||
|
Operating Temperature |
0~70℃ |
||
Pneumatic Valve,Hand Rotary Valve,Manual Operated valve
