Flange Mounting 3000RPM Rotary Vane Type Pneumatic Air Motor
Flange Mounting 3000RPM Rotary Compressor Vane-Type Air Motor Pneumatic Motor
Vane-type Air Motor4HP,3000RPM,Casting Iron and Aluminum Housing material Rotary Compressor Pneumatic Motor
Quik details:
- Use compressed air as power, safe explosion-proof, no static ,no sparks
- The rotate speed of the motor is adjusted by the pressure and flow
- No overload danger , excessive load will not damage the motor and the temperature will not rise.antly
- Self-sealing vanes and instantly reversible
- Can work continuously for a long time with full load
- Convenient operation, simple maintenance and repair.
Specifications:
| Model | Operation Data | Maximum Torque | ||||||||
| Power | Torque | Rotate Speed | Air Consumption | Rotate Speed | Torque | |||||
| hp | kW | Nm | Lb.in | rpm | m3/h | cfm | rpm | Nm | lb.in | |
| 2AM | 0.93 | 0.68 | 2.20 | 19.50 | 3000 | 49.5 | 30 | 350 | 3.05 | 26.10 |
| 4AM | 1.70 | 1.30 | 4.10 | 36.00 | 3000 | 132.5 | 78 | 300 | 6.3 | 56.00 |
| 6AM | 4.00 | 3.00 | 10.00 | 84.00 | 3000 | 228 | 128 | 300 | 13 | 115.00 |
Application:
With compressed air as medium and simple structure, small size, light weight, high horsepower, and easy to be operated and maintained. It can be worked in tough environment which is damp, high temperature, excessive dust or other harsh working environment. So it is widely used as power in mine rock drilling or petrochemical , automotive painting coating high dusty, flammable or explosive applications.
