8x4 Heavy Duty Dump Truck for Unloading, EURO II and EURO III emission standard
380HP 8x4 Heavy Duty Dump Truck HOWO A7 , Unloading Dump Trucks
Description:
- SINOTRUCK HOWO A7 series trucks own the elegant appearance, strong operation system and excellent safety.
- Sino Vehicle &Equipment Company Ltd is the authorized company of SINOTRUK(CNHTC), and mainly deal with heavy duty trucks /all spare parts and service We supply HOWO, , KING, GOLDEN PRINCE, HOHAN series 4X2, 6X4, and 8X4 dump trucks, tractor trucks, cargo trucks, garbage trucks, oil tank trucks, water tank trucks, log trailers tractors, terminal tractors, etc. Our products arrange from 190 horse power to 410 horse power, and loading capacity cover from 5 tons to 50 tons.
Application:
It is suitable for in harsh environments, unloading and transport ore and others.
Specifications:
1. howo a7 8X4 420 hp dumper trucks
2. MAN technologhy
3. large loading capacity
4. large power
wo a7 8X4 420 hp dumper trucks
|
Vehicle Model |
HOWO A7 Dump Truck A7/380/K28/8×4W |
|
Cab |
A7-W, HOWO A7 long cab, with one sleeper, with air conditioner |
|
Engine |
SINOTRUK brand,D10.38, 380hp, EUROIII emission standard |
|
Transmission |
HW19710, Nu clearance: 1900Nm |
|
Driving Axle |
AC16, Casting steel axle, double driving axle, rated payload of each axle: 16tons |
|
Front Axle |
HF9, with disc brake |
|
Steering |
ZF8098, hydraulic steering with power assistance |
|
Tires |
12.00R20 radial tire |
|
Wheel base (mm) |
2800+1350+1350 |
|
Front/rear overhang (mm) |
1500/1670 |
|
Approach/Departure angle (°) |
19/26 |
|
Maximum driving speed (km/h) |
75 |
|
Steel thickness of Cargo body (mm) |
Floor: 10 Side: 8 |
|
Lift of Carriage |
Front lift,HYVA 169 cylinder |
|
Loading capacity (kg) |
50000 |
|
Cargo body size (mm) |
6200×2300×1300 |
Function:
This truck is mainly used for transporting the stuff in bulk which can be scattered(Such as sand,soil,minerals,etc.),can also be used for integrated stuff,mainly in mining,construction sites and so on.Usually supporting the use of loaders,excavators,belt conveyors,etc..
Package&Shipping:
Company Introduction:
SINO HEAVY MACHINERY CO.,LTD. Is a professional supplier of various SINOTRUK brand trucks with more than 30 years manufacturing and exporting experience.
We mainly focus on various trucks' R&D,Producing and sales kinds of trucks with different function,such as heavy duty/medium duty/light duty truck,mining tipper,tractor truck,various construction project equipment etc...
Our all products with world-known brands spare parts,such as ZF steering and oil pump;WABCO braking system;VOSS braking connectors made in Germany;MANN+HUMMEL fuel filer system and air filter;VOD instrument and electric control block;German BEHR cooling system etc...Those high quality parts supplying ensure our products the first-class quality level and excellent driving performance.
Till now we have exported more than 30 countries and areas including Asia,Southeast Asia,Africa,South Africa etc..
We are committed to help more countries customer's engineering construction, make the world more harmonious and beautiful!
Quality Inspection:
Service:
Pre-service:
- Inquiry and Consulting support.
- Sample testing support.
- View our factory.
- Design various solutions as buyer's requirement.
After-sale service:
- Training how to use and maintain the truck.
- Our engineers supply the support of technology.
- 12 months warranty for 3 key spare parts(Engine,Transmission,Axle)
- Parts supply on time.
- 24 hours service and technology support.
