9.1T Operating Weight Shantui Bulldozer With Electronic Control Cummins Engine
9.1T Operating Weight Shantui Bulldozer With Electronic Control Cummins Engine
Email:dorinyang@road-machine.com
Skype:008618678785501
Tel:0086-18678785501
QQ:876992627
Description:
With an electronically controlled engine, the SD10YE meets Tier 3/Stage ⅢA levels for European and American off-road motor vehicles;Continuous variable transmission and localized
rotary functions;
Specifications:
|
ITEM |
UNIT |
SD10YE |
|
L×W×H (Ripper not included) |
mm |
4285×2740×2777 |
|
Operating weight (Ripper not included) |
t |
9.1 |
|
Engine |
- |
CUMMINS QSB4.5 |
|
Rated power |
kW/rpm |
74/2200 |
|
Gradeability |
° |
30 |
|
Blade type |
- |
Straight tilt blade |
|
Blade width |
mm |
2740×890 |
|
Dozing capacity |
m3 |
2.2 |
|
Ma× drop below ground of blade |
mm |
440 |
|
Lift height of blade |
mm |
890 |
|
Ripper type |
- |
- |
|
Ripping depth of ripper |
mm |
- |
|
Lifting height of ripper |
mm |
- |
|
Number of carriers (each side) |
- |
1 |
|
Number of track rollers (each side) |
- |
6 |
|
Number of track shoes (each side) |
- |
39 |
|
Width of track shoe |
mm |
460 |
|
Track gauge |
mm |
1650 |
|
Ground length and ground pressure |
mm/MPa |
2360-0.04 |
|
Pitch |
mm |
171.45 |
|
Forward speed |
km/h |
0–4.3 |
|
0–6.5 |
||
|
0–8.5 |
||
|
Reverse speed |
km/h |
0–4.3 |
|
0–6.5 |
