for sale SINOTRUK HOWO 6 X 4 heavy duty dump truck 40 ton 10 wheel tipper truck
SINOTRUCK HOWO series trucks own the elegant appearance, strong operation system and excellent safety.
Sino Heavy Machinery Co,Ltd is the authorized company of SINOTRUK(CNHTC), and mainly deal with heavy duty trucks /all spare parts and service We supply HOWO, , KING, GOLDEN PRINCE, HOHAN series 4X2, 6X4, and 8X4 dump trucks, tractor trucks, cargo trucks, garbage trucks, oil tank trucks, water tank trucks, log trailers tractors, terminal tractors, etc. Our products arrange from 190 horse power to 410 horse power, and loading capacity cover from 5 tons to 50 tons.
SPECIFICATION:
| Truck Model No: | CVZZ3257M3247N1 |
| Gross weight kg | 25000 |
| curb weight kg | 11950 |
| Rated load quality kg | 12920 |
| Max. Speed (Km/h) | 78 |
| Cab | with one sleeper, with air conditioner |
|
Engine |
Make : SINOTRUK Diesel: 4-stroke direct injection diesel engine Engine model : WD615.87, EURII emission , new design on intake & exhaust system, power and fuel economy get improved 6-cylinder in-line with water cooling, turbo-charging and intercooling Max. output : 336Hp (221 Kw ) at 2200 rpm Displacement : 9.726L |
|
Transmission |
HW15710 ,10gear transmission SINOTRUK 10 forward & 2 Ratio:14.28 Torque: 1900Nm |
| clutch | SINOTRUK Φ430 C size clutch |
|
Driving Axle |
AC16 Strengthen widen whole steel-cast 16T off road axle with double decelerator and double tires Ratio:4.77 |
| Front axle |
HF9 steel-cast 9T font axle,stick brake |
|
Braking system |
Service brake: dual circuit compressed air brake Parking brake: spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake Option:ABS |
| Electrical System | Operating voltage:24V, negative grounded |
| Steering | ZF8098 German Hydraulic steering with powder assistance |
| Wheel & Tyres |
12.00-20 No.of Tyres:10+1 |
| No. of Spring | 10/12 |
| Front/ Rear axles loading capacity (kg) | 7000 /18000 |
| No. of axles | 3 |
| Wheel base mm | 3225+1350 |
| Front/ Rear wheel track mm | 2041/1830 |
| Front/Rear hanging mm | 1540/1550 |
| Approach/ Departure angle (°) | 20 /29 |
| Dimensions(L×W×H) (mm) | 7665*2496*3490 |
| Van dimension mm |
4800*2300*1500 F style lifting cylinder Thickness: floor 8mm side 6mm |
Package&Shipping:
Company Introduction:
SINO HEAVY MACHINERY CO.,LTD. Is a professional supplier of various SINOTRUK brand trucks with more than 30 years manufacturing and exporting experience.
We mainly focus on various trucks' R&D,Producing and sales kinds of trucks with different function,such as heavy duty/medium duty/light duty truck,mining tipper,tractor truck,various construction project equipment etc...
Our all products with world-known brands spare parts,such as ZF steering and oil pump;WABCO braking system;VOSS braking connectors made in Germany;MANN+HUMMEL fuel filer system and air filter;VOD instrument and electric control block;German BEHR cooling system etc...Those high quality parts supplying ensure our products the first-class quality level and excellent driving performance.
Till now we have exported more than 30 countries and areas including Asia,Southeast Asia,Africa,South Africa etc..
We are committed to help more countries customer's engineering construction, make the world more harmonious and beautiful!
Quality Inspection:
Service:
Pre-service:
- Inquiry and Consulting support.
- Sample testing support.
- View our factory.
- Design various solutions as buyer's requirement.
After-sale service:
- Training how to use and maintain the truck.
- Our engineers supply the support of technology.
- 12 months warranty for 3 key spare parts(Engine,Transmission,Axle)
- Parts supply on time.
- 24 hours service and technology support.
