220HP Loading 5T Compact Wheel Loader With 3m³ Bucket 3550mm Ground Clearance
Introduction
1. The strong breakout force of 17 ton and strong traction of 17.5 ton ensure that the machine could adapt to various tough condition.
2. Reliable operation: with the long wheelbase of 3300mm and long machine body of 8185mm, the machine is ahead in the industry in terms of the operation reliability.
3. Quick action: the total time of three devices is only 10.3s, and the speed is 11.5 kmhour during the operation.
Powerful WEICHAI Engine
Hydraulic Transmission & Torque Converter
Pilot Control as Optional
Standard Air Condition
Variety with Attachment
Convenient Maintenance
Standard equipped with high-powered WD10G240E21 engine.
Effective homemade torque converter, Transmission and drive axle that perfect matched with the engine.
Short wheelbase lay out design, light and flexible.
CDM853 can select machinery flexible control or pilot control.
CDM853 Standard equipped with detachable cab,Comfortable and safe cab that conforms to ergonomics design.
Rational layout of the electrical system circuit ensures high safety and longer service life.
Specifications
| Bucket capacity | 3.0M³ |
| Rated load | 5000kg |
| Rated time | 6 secretary |
| Total cycling time | 11secretary |
| Max.drawing force | 145Kn |
| Max.breakout force | 170Kn |
| Articulation angle | 35. |
| Min.turn radius | 6400mm |
| Climb ability | 28. |
| Wheel base | 3300mm |
| Tread | 2200mm |
| Dumping clearance | 3090mm |
| Dumping reach | 1130mm |
| L×W×H | 8110×3000×3508mm |
| Operating weight | 18t |
| Clamp type | |
|---|---|
| Min.clamping diameter | φ450φ800mm |
| Dumping clearance | 3230mm |
| Dumping reach | 1845mm |
| L×W×H | 8414×2800×3460mm |
| Operating weight | 18t |
Photos
Other Truck can be provide according to your request, freely contact me for the informations and quotations.
