Sinotruk Howo Prime Mover Truck 336hp 4x2 Tractor Truck Dimension 6110 X 2496 X 2958mm With 2.0inch
Specification:
|
Model |
ZZ4187M3517C1 |
|
|
Dimension(lenght x width x height)(mm) |
6110X2496X2958 |
|
|
Gross weight (kg) |
18000 |
|
|
Total weight(kg) |
7100 |
|
|
Max speed (km/h) |
102 |
|
|
Wheelbase(mm) |
3500 |
|
|
Engine |
Mode |
WD615.97C |
|
|
Rated engine power(kW/r/min) |
221/1900 |
|
|
Max torque (N.m/r/min) |
1340/1200~1500 |
|
Clutch |
φ430mm diaphragm spring clutch |
|
|
Gearbox |
Mode |
HW13710 |
|
|
Ratio |
10.73 7.98 5.91 4.38 3.29 2.45 1.82 1.35 1.00 0.75 R1 10.49 R2 2.39 |
|
Drive axle |
HW1249 single rear axle ,i=3.91 |
|
|
Steering |
ZF8098 |
|
|
Transfer |
mode |
1200 |
|
|
High-grade/low-grade ratio |
1.00/1.75 |
|
Brake type |
service braking; dual circuit compressed air brake; parking brake(hand brake),spring energy air cut brake |
|
|
Cab |
HOWO76 cab |
|
|
Electric system |
HOWO electric system ,24V,negarive grounded |
|
|
Tire |
12.00-20 |
|
|
Fuel tank(L) |
400 |
|
|
Option engine model |
WD615.92C,WD615.97C
|
|
Our aim is:
to use our products to make your project value-added!
To use our products to make your city and country more clean, beautiful and modern!
Our Principal: honest innovation Cherish life protect environment
1:Any inquiry will be replied within 24 hours.
2.Well-trained and experienced staff to answer all your inquiries .
3.Factory visit is welcomed and free booking hotel and airport pick up service.
4. Engineers will go to clients' site for guiding the installation and test-running.
5.Spare parts supply,We will keep your know the complete data, when you need any spare parts, we will send to you in a fast way.
6.15 months super long time guarantee period.
7. For the dump truck and semi trailer,it's half a year,If there are some quality problems in axle,transmission,engine,etc,and confirmed it's really the quality problems,we'll send the parts free,but man wrong operation and daily fast moving spare parts are not included,for the trailer,the electric systems and fast moving spare parts are not included.
PS:
We have our own spare parts departments .we can satisfy your demand within 10days .
Transport
Truck is nude packing, shipping in container, in bulk ,in ro-ro.
We will choose the best shipping type based on truck volume, truck structure, Sail Schedule, clients’ requirement for clients!
