SY16 Lower Fuel Hydraulic Crawler Excavator Wide Applications In Narrow Spaces
Price:
Negotiable
MOQ:
1
Delivery Time:
Within 35 days
Brand:
CIVL
Product Description
Transport length3575 mm
Transport width980/1350 mm
Transport height2420 mm
Std. track shoe width230 mm
Track gauge750/1120 mm
Min. ground clearance180 mm
Tail swing radius920 mm
Roller gauge1225 mm
Max. digging height3665 mm
Max. dumping height2635 mm
Max. digging depth2360 mm
Max. vertical digging depth2215 mm
Max. digging reach4000 mm
Min. swing radius1655 mm
Engine model3TNV74F/3TNV70
Engine rated Power11.2/2400 kW/rpm
Engine displacement0.993/0.854 L
Overall weight1750 kg
Bucket capacity0.04 m3
Bucket digging force15.2 kN
Arm digging force9.2 kN
Travel speed (high/low)3.7/2.1 km/h
Swing speed10 rpm
Gradeability58%/30°
Ground pressure29.1 kPa
Fuel tank capacity23 L
Arm length1130 m
Bulldozer Blade - width*heigh1350×270 mm
Bulldozer blade - raise/lower310×320 mm
Hyd tank capacity21 L
Boom length1810 m
