Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
Diesel Engine 30 Tons Tipper Truck , Low Noise Dump Truck Heavy Duty
30 Tons Tipper Truck Description:
HOWO6 × 6 all-wheel drive can be used as transport vehicles, various types of transport, fuel trucks, all types of transportation equipment chassis, suitable for off-road transport, towing equipment, transport operations oil, mining, forestry, fire fighting equipment and various types of special vehicle modification needs .
High strength/ high rigidity/ long life block: vermicular cast iron body, similar strength cast steel, similar heat dissipation potential gray iron, strong anti-thermal deformation, high cost, can be adopted in few high end engines in the world due to its core technology.
1). Good economy: high-explosive pressure and optimized injection and combustion system, ensuring its low specific oil consumption at a wide range of sppds, Minimum specific oil consumption is 186/kwh.
2). Low nose: noise reaches the international level.
3). High-integration: volume of spare parts reduced 25% compared with the similar products in the world, highly reducing the failure points.
4). Long life of B10: reach the most advanced world level of heavy duty truck, 1.5 million km.
5). Long oil change interval: for Euro IV oil, the first oil change mileage( oil change interval) for the road vehicles since left factory shall be up to 100.000 km, for the oil selling bu Petrochina and Sinopec. it shall be up to 60.000 km, greatly reducing the cost.
30 Tons Tipper Truck Specifications:
|
Model |
6x6 dump truck Based on using STR technology |
|
|
Gear box |
American technology |
Max torque:1600NM |
|
|
Model: |
HW15710C |
|
|
Speed: |
15speed, 2reverse |
|
Axle(front/rear) |
||
|
Front axle |
9T STR technology non-driving steering axle |
|
|
Tandem |
16T STR technology double reduction, hub redactor driving axle |
|
|
Clutch |
D430 diaphragm type, single dry frictional disc, hydraulic boosting |
|
|
Brake |
Service brake: Double circuit pneumatic brake |
|
|
|
Parking brake: Spring-Power drum brake |
|
|
|
Engine brake: Engine exhaust brake (EVB) |
|
|
Steering |
ZF8118, driver sit at the Left hand side, RHD is optional |
|
|
Electric Equipment |
||
|
|
Operating voltage: |
24Vnegative grounded |
|
|
Starter: |
24V,5.4KW |
|
|
Alternator |
28V,758W |
|
|
Battery voltage |
12V/135Ah, cigar lighter |
|
Frame |
Strengthen steel frame, designed according to tough road condition. |
|
|
Tyre |
10+1 spare tyre with rim |
|
|
|
12.00-20 bias tyre |
|
|
Suspension system: Strengthen heavy duty Leaf spring type |
||
|
|
Front/Rear |
10/12 |
|
Dump body: type of body : |
||
|
Inside size of Body(mm): 5170x2300x1500, 8x6mm (thickness of floor and rail of the dump body) |
||
|
Lifting type: HYVA front lifter type hydraulic system |
||
|
Overall dimension(mm): 11868x2496x3250 (Length x width x height) |
||
|
Wheelbase |
3800+1400mm |
|
|
Track: |
|
|
|
|
Front/Rear |
2036/1850 |
|
|
Approach/Departure angle |
28/30 |
|
|
Front /Rear overhang |
1525/1654 |
|
|
Max speed |
90km/h |
|
Curb weight: |
12190kg |
|
