Terminal Surface Box Beam Production Line End Face Milling Machine For Beam Column
Terminal Surface End Face Miller Machine For Beam Column / H Beam
1. Feature
It is such a Machine Tools, used to Mill the End face & Bevel face of Various-size metal workpiece, also with boring drilling feature for T Slots & Dovetail groove.
2. Main charactors:
● Rotatable workhead, 45 degree.
● Universal function, with Drilling Boring feature.
● Worktable & Head are controlled by Panel, Operates simply.
● Increased vertical column weight, better stability.
● High accuracy, error within 0.05mm.
● Adopts tempered cast, indeformable.
● Hand scraping table surface & body face, more smooth.
3. Technical parameter
|
Item Type |
Unit |
DX1180 |
DX1250 |
DX1300 |
|
|
Table |
Size L×W |
mm |
1800×680 |
2000×680 |
3000×800 |
|
Table Travel |
mm |
1800 |
2500 |
3500 |
|
|
Given Speed |
mm/min |
Infinitive Speed |
|||
|
Given Motor |
kw |
2.2 |
2.2 |
3 |
|
|
Head |
Vertical Travel |
mm |
900 |
1000 |
1500 |
|
Transversal Travel |
mm |
550 |
550 |
550 |
|
|
Adjustable Angle |
degree |
- |
- |
50 |
|
|
Milling cutter Dia |
mm |
250 |
250 |
250 |
|
|
Lifting Motor |
kw |
1.5 |
1.5 |
2.2 |
|
|
Spindle |
Spindle Diameter |
mm |
130 |
130 |
130 |
|
Spindle Speed |
mm/min |
150/ 300/ 420 |
|||
|
Transversal Travel |
mm |
120 |
120 |
120 |
|
|
Taper |
- |
7:24 |
7:24 |
7:24 |
|
|
Main Motor |
kw |
7.5 |
7.5 |
11 |
|
|
Control System |
- |
Control Panel |
Control Panel |
Control Panel |
|
|
T-Slots No. |
pcs |
4 |
4 |
5 |
|
|
Overall Dimension L×W×H |
mm |
3800×1680×2000 |
4300×1800×2000 |
5200×2200×3060 |
|
|
Total Weight |
kg |
4200 |
4800 |
8000 |
|
