Hook Type Steel Tube Shot Blasting Machine For Casting And Forging
Hook Type Steel Tube Shot Blasting Machine For Casting And Forging
1. Model feature
● Hanger type shot blasting machine
● Fit for Casting industry
● Double hanger
2. Machine details
|
Model |
Unit |
HP376 |
HP378 |
HP3710 |
HP3720 |
HP3730 |
HP3750 |
|
Size of jobs |
mm |
600*1100 |
800*1500 |
800*1850 |
1400*2300 |
1600*2200 |
1800*2500 |
|
Loading per |
kg |
600 |
1000 |
1000 |
2000 |
3000 |
5000 |
|
Blasting volume |
kg/min |
2*120 |
2*200 |
2*250 |
3*250 |
3*250 |
4*250 |
|
Lifting |
t/h |
15 |
24 |
30 |
45 |
45 |
60 |
|
Separating |
t/h |
15 |
24 |
30 |
45 |
45 |
60 |
|
Air volume |
cum/h |
2800 |
4500 |
6600 |
8300 |
12000 |
15000 |
|
Total power |
kw |
25.14 |
34.14 |
36.55 |
61.27 |
64.4 |
78.4 |
|
Outsize of machine |
mm |
4500*2500 *4600 |
5000*3000 *5000 |
5844*2742 *5716 |
6110*3599 *7842 |
7085*4650 *7200 |
7062*5460 *8000 |
|
Feature of machine |
The jobs are hung on hooker and then enter into blasting room to accept hit of high speed of steel shots. There is self-rotation device in hooks which can make jobs rotate in blasting room. It applies to intensify and remove away sand and oxide layers of medium and large size of casting, forging steel structure and so on. Q378 shot blasting machine has the advantage of no trench design, double hooks, compact structure, high productivity etc. |
||||||
