Small Benchtop Welding Positioner / Positioning Rotating Machine For Tank Welding
Small Benchtop Welding Positioner / Positioning Rotating Machine For Tank Welding
1. Machine features
Small-block positioner driven by DC motor can achieve stepless speed regulation. Controller using computer control can link well with the welding positioner.
A professional anti-EMI design is used for this product; high-frequency interference can be avoided when welding.
Power system with reverse worm wheel system, have the function of self-locking mechanism.
Table tilting angle at 0-90 °, can realize stepless turn.
According to customer’s requirements, welding gun bracket, regulatory devices track and pneumatic finial can be configured,in order to realize automatic weld.
2. Machine date
|
Model No. |
WP-01 |
WP-05 |
WP-1 |
WP-3 |
WP-5 |
|
|
Basic loading (ton) |
0.1 |
0.5 |
1 |
3 |
5 |
|
|
Rotating speed (r/min) |
2-20 |
1-7/15 |
0.2-7/15 |
0.2-2.5 |
0.05-0.5 |
|
|
Tilting speed (r/min) |
Manual Turning |
Manual Turning |
Manual Turning |
Manual Turning |
0.5 |
|
|
Tilting angle (° ) |
0~90 |
0~90 |
0~90 |
0~90 |
0~90 |
|
|
Work table diameter (mm) |
180 |
315 |
345 |
450 |
650 |
|
|
Height of work Table (mm) |
215 |
375 |
415 |
500 |
675 |
|
|
Allow workpiece off -center (mm) |
Centroid eccentricity |
-- |
-- |
-- |
150 |
300 |
|
Centroidal height |
-- |
-- |
-- |
-- |
300 |
|
|
Rotating motor power (w) |
10 |
80 |
120 |
200 |
300 |
|
|
Tilting motor power (w) |
-- |
-- |
-- |
-- |
300 |
|
|
Dimension |
L (mm) |
370 |
430 |
500 |
500 |
650 |
|
B (mm) |
270 |
430 |
470 |
520 |
800 |
|
|
H (mm) |
215 |
375 |
415 |
500 |
675 |
|
2.
